MOSFET Gate Drivers, LDOs and DC-DC Controllers: A Selection and Sourcing Guide

Power management sits between your supply and everything else on the board. Get it right and nobody notices; get it wrong and you get heat, noise, resets, or a MOSFET that fails in the field. This guide walks through the three blocks we are asked about most — MOSFET gate drivers, low-dropout linear regulators, and PWM controllers or DC-DC converters — and the alternatives we stock for each.

MOSFET gate drivers

A MOSFET gate looks like a capacitor. To switch quickly you must move charge into and out of that capacitor fast, and a microcontroller pin generally cannot. A gate driver is a buffer that supplies the peak current needed, so the MOSFET spends as little time as possible in its linear region.

• Peak output current — determines how fast you can switch. Higher current, faster edges, lower switching loss.
• Channels and polarity — single, dual inverting, dual non-inverting, or complementary pairs.
• Supply range and input logic — confirm the driver works at your rail and accepts your logic levels.
• High-side capability — driving a high-side N-channel MOSFET needs a bootstrap supply.

For low-side and general-purpose driving we stock the COS4427SR and COS4426SR dual drivers, plus the complementary COS4428SR. For high-voltage half-bridge work, the COS2184S and COS2113PBF cover the 600 V class.

Low-dropout linear regulators

An LDO trades efficiency for simplicity, low noise and low cost. It is still the right answer for noise-sensitive analogue rails and for small voltage drops. The parameters that matter are dropout voltage at your load current, quiescent current, PSRR across frequency, and thermal capability in the package you have space for.

We supply the COS29502WU and COS29302WU for higher-current low-dropout requirements.

PWM controllers and DC-DC converters

For anything other than a small voltage drop, a switching converter is far more efficient. Current-mode PWM controllers remain the backbone of off-line and isolated supplies, while synchronous buck regulators dominate point-of-load conversion.

We stock the COS3842BD for UC3842 class current-mode control, the COS3525ADW for SG3525ADW class push-pull and half-bridge work, and the JW5060T for MP1584EN class buck conversion.

Selection checklist

• Define the input range, output and maximum load current first — everything else follows.
• For switching converters, size the inductor for your ripple target and check the switch current limit.
• Check thermal performance in the actual package and copper area; datasheet currents assume good layout.
• Confirm enable, soft-start and sequencing behaviour if multiple rails must come up in order.
• Verify pinout and package against the datasheet before substituting any alternative.

Power management parts we stock

See the wider power management range and amplifiers and data conversion categories. Send your input range, output, current and package for a quote.

Frequently asked questions

What peak current do I need from a MOSFET gate driver?

It depends on the total gate charge you must move and how fast you need to move it. As a rule of thumb, divide the gate charge by your desired rise time to get the average current, then choose a driver with a peak rating comfortably above that. Under-driving a gate causes slow switching, which increases switching loss and heats the MOSFET.

When should I use a half-bridge driver instead of a low-side driver?

Use a half-bridge driver whenever you are switching a high-side N-channel MOSFET, because its gate must be driven above the supply rail. That needs a bootstrap or charge-pump supply, which IRS2184 and IRS2113 class devices integrate.

What does 'low dropout' actually mean?

Dropout is the minimum difference between input and output voltage at which the regulator still regulates. A lower dropout lets you run from a supply closer to your output voltage, which improves efficiency and extends battery life.

Are these parts drop-in replacements?

The COSINE parts listed are designed against the pinout and function of the referenced devices, but you must confirm the package, pinout and electrical limits against the datasheet for your specific application before committing to volume.
