RF Filter Selection Guide: LTCC Low-Pass, High-Pass and Band-Pass Filters Compared

Filters decide what your receiver actually hears and what your transmitter is allowed to emit. Getting the filter right is usually cheaper than adding gain later, and getting it wrong is the classic cause of a design that passes bench testing and fails compliance. This guide covers the three filter families we stock most — LTCC low-pass, high-pass and band-pass parts, plus SAW and BAW devices — and how to choose between them.

1. Start from the problem, not the part number

Before looking at a catalogue, write down three things: the band you must pass, the band you must reject, and how much loss you can tolerate. Those three numbers eliminate most candidates immediately.

• Harmonics after an amplifier or mixer — low-pass.
• Blocking DC, LO leakage or low-frequency energy — high-pass.
• Selecting one band out of many — band-pass, and often a SAW or BAW device.

2. LTCC low-pass filters

Low-pass filters are the workhorse for cleaning up harmonic content and for meeting emission limits at the output of a transmitter chain. LTCC construction gives consistent response in a tiny footprint.

3. LTCC high-pass filters

High-pass parts are used to strip out low-frequency energy, protect a following stage from DC, and reject the low side of a mixed signal.

4. LTCC band-pass filters

When you only care about one window of spectrum, a band-pass part gives you rejection on both sides in a single component.

5. SAW and BAW devices

Where the band is crowded or the selectivity requirement is tight, acoustic-wave filters give far steeper skirts than an LC or LTCC network can achieve in the same space.

Selection checklist

• Define pass band, reject band and acceptable insertion loss before shortlisting.
• Match the cutoff or centre frequency to your actual operating band, including tolerance.
• Check the package footprint and termination finish against your assembly process.
• Confirm power handling if the filter sits after a power amplifier.
• Verify the response on your own board — layout and grounding shift real-world results.

Browse the wider filter and timing component range. Send us your band, cutoff and package for a real-time quote.

Frequently asked questions

What is the difference between a low-pass, high-pass and band-pass RF filter?

A low-pass filter passes everything below its cutoff and rejects above it, which is the usual choice for cleaning up harmonic content after an amplifier or mixer. A high-pass filter does the reverse and is used to block DC and low-frequency energy. A band-pass filter passes one window of frequencies and rejects both sides, which is what you want in front of a receiver that only cares about one band.

When should I use an LTCC filter instead of a discrete LC filter?

Use an LTCC (low-temperature co-fired ceramic) filter when you need repeatable response, tight size and good rejection without tuning. Discrete LC filters are cheap and flexible but need component tolerance control and layout care, and they vary more unit to unit. LTCC parts are the standard choice when the design goes to volume.

What is the difference between a SAW filter and a BAW filter?

SAW (surface acoustic wave) filters are widely used up to roughly 2 to 2.5 GHz and are cost-effective with good selectivity. BAW (bulk acoustic wave) filters reach higher frequencies with steeper skirts and better power handling and temperature behaviour, which is why they appear in higher-band designs. Choose SAW for cost at lower bands and BAW where the band is crowded or the frequency is high.

How do I read the part number on a Mini-Circuits style filter?

In the family used widely across the industry, LFCN denotes a low-pass filter, HFCN a high-pass filter and BFCN a band-pass filter; the number that follows indicates the cutoff or centre frequency. Always confirm the exact cutoff, passband and package against the manufacturer datasheet before ordering, because suffixes and package variants change the footprint.
