ATN3580-10 by Skyworks is a component in the Fixed Attenuator (thin-film silicon chip, DC-40 GHz) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The ATN3580-10 is the 10 dB member of Skyworks' ATN3580 thin-film attenuator pad family, offering a flat 10 dB response from DC to 40 GHz in a 0.51 x 0.686 mm silicon die. The balanced TEE thin-film resistor structure provides ±0.35 dB DC tolerance, ±0.2 dB flatness to 12 GHz, 15 dB minimum return loss at 40 GHz and 1 W CW power handling. It is intended for direct die attach on microstrip or coplanar waveguide in radar, test and high-frequency transceiver designs. The series is discontinued and the part is now obsolete, available from independent stock.
Key specifications
| Part number | ATN3580-10 |
| Manufacturer | Skyworks |
| Device type | Fixed Attenuator Pad (thin-film chip attenuator) |
| Package | Bare Die |
| Package size | 0.51 x 0.686 mm die (0.020 x 0.027 in), 0.25 mm thick |
| Stock | 1,500 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Frequency range | DC to 40 GHz |
| Nominal attenuation | 10 dB |
| Attenuation tolerance at DC | ±0.35 dB |
| Attenuation flatness 0.1-12 GHz | ±0.2 dB |
| Attenuation flatness 0.1-26.5 GHz | ±0.30 dB |
| Attenuation flatness 0.1-40 GHz | ±0.50 dB |
| Return loss 0.1-7 GHz | 22 dB min |
| Return loss 0.1-12 GHz | 20 dB min |
| Return loss 0.1-26.5 GHz | 18 dB min |
| Return loss 0.1-40 GHz | 15 dB min |
| Power handling | 1 W CW (incident, 25 °C) |
| Impedance | 50 Ω |
| Operating temperature | -55 to +150 °C |
| ESD (HBM / CDM) | 2000 V / 1000 V |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: Same 518-060 die as ATN3580-07 but with 10 dB nominal attenuation and a wider ±0.35 dB DC tolerance; do not interchange electrical limits between the two. Skyworks lists it as discontinued; DigiKey lists it Obsolete (EOL 29/Apr/2026, 15/May/2026).
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 1,500 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray, tube or bulk as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for ATN3580-10? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Interface Chips / RF Chips collection for more 10 dB Fixed Attenuator Pad devices, or request a quote for ATN3580-10.
