COS2177SR
- The COS1177(single), COS2177(dual)and COS4177(quad)are low power, precision operational amplifiers operated on ±2.25V to ±18V supplies. The COSx177 family has very low input offset voltage(50μV)maximum that is obtained by trimming at the wafer stage. These low offset voltages generally eliminate any need for external nulling. The COSx177 also features low input bias current and high open-loop gain. The low offset and high open-loop gain make the COSx177 particularly useful for high gain instrumentation applications. The wide input voltage range of ±13 V minimum combined with a high CMRR of 125dB and high input impedance provide high accuracy in the noninverting circuit config- uration. Excellent linearity and gain accuracy can be maintained even at high closed-loop gains. Stability of offsets and gain with time or variations in temperature is excellent. The accuracy and stability of the COSx177, even at high gain, combined with the freedom from external nulling have made the COSx177 an ideal choice for instrumentation applications.
- • Low Offset Voltage: 50µV(Max.) • Low Drift: 0.2µV/ºC • Low Input Bias Current: 2nA(Max.) • Gain Bandwidth Product: 2MHz • Wide Supply Range：±2.25V ~ ±18V • Low Quiescent Current: 330µA • Slew Rate: 0.7V/µs • Unity Gain Stable • Input Over-Voltage Protection • Extended Temperature Ranges From -40°C to +125°C • Small Packaging • COS1177 available in SOP8/MSOP8 COS2177 available in SOP8/MSOP8 COS4177 available in SOP14/TSSOP14
Generate QR code
Product description
Shipping & Return
COS2177SR — Overview
COS2177SR is an original electronic component supplied by Shenzhen Jingteng Electronics (JTDZ Tech), serving OEMs, ODMs and EMS providers worldwide.
Key Specifications
| Part Number | COS2177SR |
| Stock Status | In stock — ships within 24 hours |
Quality Guarantee
Every order ships with date code and Certificate of Conformance (COC). Visual and X-ray inspection, and third-party inspection (White Horse, GDS, or your designated lab) are supported before shipment.
