HSMG-C650
-
When You'll Get It:Aug 25 - Aug 29
-
Shipping & Support: In-stock items ship in 24 hours; custom orders ship per contract. Free shipping on orders over $10,000. For bulk buys, get a personal support rep and quick reimbursement if anything's defective.
**Description**
- Single color surface mount chip LED
- Green LED in a standard industry footprint
- Tinted, diffused optics
- Designed for ease of handling and use
- Housed in a 2-SMD, No Lead surface mount package
- **Product Status:** Obsolete
**Features**
- Small size and low profile (1.00 mm max height)
- Industry standard footprint
- Compatible with IR soldering process
- Wide viewing angle: 155°
- Available in tape on 7" (178 mm) diameter reels
- Compatible with IR reflow soldering processes
- RoHS compliant
**Key Specifications** (Typical @ T_A = 25°C)
- Color: Green
- Lens Color: Water Clear
- Lens Transparency: Clear
- Luminous Intensity (I_V): 4.0 mcd min. / 9.0 mcd typ. @ I_F = 20 mA
- Peak Wavelength (λ_peak): 570 nm typ.
- Dominant Wavelength (λ_d): 572 nm typ.
- Viewing Angle (2θ½): 155° typ.
- Forward Voltage (V_F): 2.2 V typ. / 2.6 V max @ I_F = 20 mA
- Reverse Voltage (V_R): 5 V max
- DC Forward Current (I_F): 25 mA max
- Power Dissipation (P_D): 65 mW max
- LED Junction Temperature (T_J): 95 °C max
- Operating Temperature Range: –25°C to +80°C
- Storage Temperature Range: –30°C to +85°C
- Package / Case: 2-SMD, No Lead
- Supplier Device Package: Chip LED
- Size / Dimension: 3.00 mm L x 1.00 mm W
- Height (Max): 1.00 mm
**Applications**
- Push-button backlighting
- LCD backlighting
- Symbol backlighting
- Front panel indicator
- Front panel illumination
---
> **Note:** All parameters are subject to the official Broadcom (Avago Technologies) HSMG-C650 datasheet. Specifications are typical values and may vary with operating conditions. This product is obsolete and not recommended for new designs.
