MABACT0039 — Overview
MABACT0039 by MACOM is a component in the RF Transformer / Balun category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The MABACT0039 is a 1:1 transmission-line transformer (balun) from MACOM in a 5-lead SOT-style surface-mount package measuring 5.34 x 4.20 x 3.51 mm. It covers 5 MHz to 3 GHz with 1.0 dB typical insertion loss over 50 to 2150 MHz, +/-2.2 dB amplitude balance and +/-13 degrees phase balance, and works in both 50 ohm and 75 ohm systems. It is aimed at high-volume CATV and broadband applications and is RoHS compliant and 260 degC reflow compatible.
Key specifications
| Part number | MABACT0039 |
| Manufacturer | MACOM |
| Device type | RF Transformer (Transmission Line Balun) |
| Package | SOT-5 |
| Package size | 5.34 x 4.20 x 3.51 mm |
| Stock | 5,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Impedance ratio | 1:1 |
| Frequency range | 5 - 3000 MHz |
| Insertion loss | 1.0 dB typ / 2.0 dB max (50 - 2150 MHz); 1.5 dB typ / 3.5 dB max (5 - 3000 MHz) |
| Amplitude balance | 1.0 dB typ, +/- 2.2 dB max (50 - 2150 MHz) |
| Phase balance | 5 degrees typ, +/- 13 degrees max (50 - 2150 MHz) |
| Input return loss | 20 dB min (5 - 550 MHz); 8 dB min (550 - 2100 MHz) |
| Characteristic impedance | 50 ohm and 75 ohm systems |
| RF input power | 250 mW max |
| DC current | 30 mA max |
| Operating temperature | -40 to +85 degC |
| Pin count | 5 (primary in/ground, secondary out x2, 1 unused) |
| Packaging | Tape and reel, 2000 pcs per reel |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: Confirmed as a transformer/balun (not a coupler). Verified against the MACOM datasheet DS-MABACT0039 and the MACOM product page, which lists package 'SOT 5.34x4.20x3.51mm' with 5 leads.
