PC817X1CSP9F — Overview
PC817X1CSP9F by Sharp is a high-volume electronic component supplied by Shenzhen Jingteng Electronics (JTDZ Tech). Transistor-output optocoupler, the highest-volume part for isolation circuits. We keep this part in stock for OEMs, ODMs and EMS providers in India, Vietnam and the Middle East.
Key Specifications
| Part Number | PC817X1CSP9F |
| Manufacturer | Sharp |
| Category | Sensors / Optoelectronic Devices |
| Package | SOP-4 |
| Pin Count | 4 |
| Isolation Voltage | 5000 Vrms |
| CTR | 50 - 600 % (rank dependent) |
| Collector-Emitter Voltage | 80 V min |
| Forward Current | 50 mA max |
| Collector Current | 50 mA max |
| Package | SOP-4 |
| Response Time | 4 µs typical |
| Operating Temp | -30 °C to +100 °C |
| Date Code | Recent date code, factory |
| Stock Status | In stock — ships within 24 hours |
| Description | Sensors / Optoelectronic Devices, -30 °C to +100 °C, SOP-4 package. |
Typical Applications
Power supply feedback, PLC I/O isolation, MCU signal isolation, chargers.
Why Buy PC817X1CSP9F from JTDZ Tech
- Verified and new parts, traceable date code, Certificate of Conformance available
- MOQ 1 pc, tier pricing for volume orders
- X-ray and visual inspection, third-party lab test (White Horse / GDS) supported before shipment
- Quote within 2 business hours, export shipping to India, Vietnam, the Middle East and worldwide
Genuine original parts guaranteed — traceable lot & date code, X-ray / visual inspection and third-party test supported before shipment.
PC817X1CSP9F — Sharp transistor-output optocoupler, the highest-volume part for isolation circuits
The PC817X1CSP9F is listed by Jingteng Electronics as a Sharp sensor or optoelectronic device in the Sensors & Optoelectronic Devices category. We supply it as a genuine, original part sourced through verified channels, suitable for buyers who need reliable, fast-turn component sourcing.
Typical Applications
As a sensor or optoelectronic device, this component is commonly designed into equipment that relies on Sensors & Optoelectronic Devices. Sensors and optoelectronic devices convert physical signals into electrical ones or emit light. They serve position, proximity, ambient-light, image and optical-link functions in automotive, industrial sensing, displays and communication modules.
Authenticity & Sourcing
Jingteng supplies Sharp PC817X1CSP9F as genuine and original stock. Sharp is a third-party trademark referenced here only to identify the component; Jingteng is an independent distributor and does not act as an agent of the component manufacturer.
Request a Quote for PC817X1CSP9F
Need pricing or availability for PC817X1CSP9F? Send the part number and your target quantity and our team replies within 2 business hours with a quote.
