PE613050A-Z — Overview
PE613050A-Z by Peregrine is a SP4T Tuning Control Switch in a QFN-12 (2 × 2 × 0.5 mm) package, supplied by Shenzhen Jingteng Electronics (JTDZ Tech). An SP4T tuning control switch based on Peregrine’s UltraCMOS® technology, supporting impedance-matching and aperture-tuning topologies from 5 to 3000 MHz with low on-resistance and insertion loss. Two-pin CMOS control; all decoding and biasing is integrated on-chip, so no external bypassing or filtering components are required.
Key Specifications
| Part Number | PE613050A-Z |
|---|---|
| Manufacturer | Peregrine Semiconductor (pSemi) |
| Device Type | SP4T Tuning Control Switch (UltraCMOS®) |
| Frequency Range | 5 – 3000 MHz |
| Insertion Loss | 0.2 dB typ (0.55 dB max) |
| Isolation | 28 dB typ (17 dB min) |
| On-Resistance | 1.6 Ω |
| P0.1dB | 35.1 dBm |
| IIP3 | 80 dBm |
| Supply Voltage | 2.3 – 5.5 V |
| Package | 12L QFN, 2 × 2 × 0.5 mm |
Datasheet Parameters
| Architecture | Open reflective SP4T |
|---|---|
| Insertion Loss | 0.2 dB typ / 0.55 dB max |
| Isolation | 28 dB typ / 17 dB min |
| On-Resistance | 1.6 Ω |
| Off Capacitance | 0.14 pF |
| IIP3 | 80 dBm |
| Switching Time | 2 µs (ESD 2 kV HBM) |
Applications
- antenna impedance matching
- aperture tuning
- cellular / LTE tuning circuits
- RF tuning in wireless handsets
Stock & Packaging
Active product, in stock at JTDZ Tech. Original, genuine and unused parts with traceable date code; Certificate of Conformity available on request. Ships within 24 hours from JTDZ Tech stock.
FAQ
- Is the PE613050A-Z genuine and traceable?
Yes. JTDZ Tech (Shenzhen Jinteng Electronics) supplies the Peregrine PE613050A-Z as original, genuine parts with traceable date codes and a Certificate of Conformity available on request. - What package does the PE613050A-Z use?
It is housed in a QFN-12 (2 × 2 × 0.5 mm) package, suitable for automated assembly and high-density RF / microwave designs. - What are the typical applications of the PE613050A-Z?
It targets antenna impedance-matching and aperture-tuning applications, cellular/LTE tuning circuits and RF tuning in wireless handsets and modules. - Is the PE613050A-Z still in production?
Active product, in stock at JTDZ Tech. - What is the lead time and shipping?
In stock at JTDZ Tech — ships within 24 hours. Each lot carries a traceable date code; small-batch, prototype and repair quantities are supported. - Can I get the full datasheet?
Yes. The complete Peregrine PE613050A-Z datasheet (electrical characteristics, S-parameters, footprint and reel specs) is available on request — contact JTDZ Tech sales for the PDF and reference designs.
Related Peregrine Products
Browse our full Peregrine inventory at JTDZ Tech for more RF / microwave components, or contact us for cross-reference and volume pricing.
Specifications are based on the Peregrine PE613050A-Z datasheet. JTDZ Tech is an independent distributor of original Peregrine components; this page is for technical reference and procurement only.
