SN74AXC4T774RSVR — Overview
SN74AXC4T774RSVR by Texas Instruments is a component in the 4-Bit Dual-Supply Bus Transceiver / Voltage Level Translator (independent direction control, tri-state outputs) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The SN74AXC4T774RSVR is a 4-bit non-inverting dual-supply bus transceiver from Texas Instruments that provides configurable voltage translation with independent direction control for each channel. Both supply rails (VCCA and VCCB) can operate from 0.65 V to 3.6 V, supporting down- and up-translation at data rates up to 310 Mbps (1.8 V to 3.3 V). Tri-state outputs, an output-enable pin, glitch-free power-supply sequencing and VCC isolation make it well suited to interfacing mixed-voltage logic and buses in portable, industrial and communication systems.
Key specifications
| Part number | SN74AXC4T774RSVR |
| Manufacturer | Texas Instruments |
| Device type | 4-Bit Dual-Supply Bus Transceiver / Voltage Level Translator (independent direction control, tri-state outputs) |
| Package | UQFN-16 |
| Package size | 2.60 x 1.80 mm |
| Stock | 20,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Function | 4-bit non-inverting dual-supply bus transceiver / voltage level translator |
| Channels | 4 bits with independent direction control per channel |
| Supply voltage (VCCA / VCCB) | 0.65 V to 3.6 V each (fully configurable dual rail) |
| Data rate | Up to 310 Mbps (1.8 V to 3.3 V translation) |
| Direction control | 4 x DIR pins (referenced to VCCA) |
| Output enable | OE pin (active low, referenced to VCCA) |
| Propagation delay | 5 ns (max) |
| Supply current | 0.04 mA (max) |
| Output type | Tri-state outputs; glitch-free power-supply sequencing |
| VCC isolation | If either VCC < 100 mV, all I/Os are disabled (high-impedance) |
| Partial power-down | Ioff supports partial-power-down operation |
| ESD protection | ±8000 V HBM, ±1000 V CDM |
| Operating temperature | -40 to +125 °C |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 20,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray or tube as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for SN74AXC4T774RSVR? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Memory / Logic Devices collection for more 4-Bit Level Translator devices, or request a quote for SN74AXC4T774RSVR.
Other Texas Instruments parts in stock
| CDCP1803RGER | LM1391N | ADS1291IRSMR |
| LM35DZ | CD40106BM | CD4066BM |
Frequently asked questions
Is SN74AXC4T774RSVR original and genuine?
Yes. We supply SN74AXC4T774RSVR as original, unused stock sourced through long-verified, traceable channels. Traceability documents, inspection reports and photos of the actual goods can be provided on request before you commit.
How much SN74AXC4T774RSVR stock do you have?
20,000 pcs of SN74AXC4T774RSVR are currently listed. Stock moves daily - send us your required quantity and we will confirm live availability, date code and lead time.
What package does SN74AXC4T774RSVR use?
SN74AXC4T774RSVR is supplied in a UQFN-16 package (2.60 x 1.80 mm). Always confirm the package, pinout and thermal pad layout against the current manufacturer datasheet before design-in.
Can you help confirm the SN74AXC4T774RSVR parameters?
Yes. Tell us the parameters you are qualifying (supply voltage, current rating, frequency, interface, temperature range or package) and our team will help you confirm them against the current manufacturer datasheet. We do not host third-party datasheets.
Do you quote volume orders for SN74AXC4T774RSVR?
Yes. We quote volume pricing, available quantity and lead time within 2 working hours, and we can consolidate SN74AXC4T774RSVR with other line items into a single shipment.
