TDA21472 — Overview
TDA21472 by Infineon Technologies is a component in the Power Management - Integrated Power Stage (DrMOS / Smart Power Stage) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The TDA21472 is an Infineon OptiMOS integrated power stage (DrMOS) that co-packages a low-quiescent-current synchronous buck gate driver with a Schottky diode and high-side/low-side MOSFETs in a 5 x 6 x 1 mm PQFN (Infineon PG-IQFN-39) package. It delivers up to 70 A continuous output (80-A OCP), operates from a 4.25-V to 16-V input at switching frequencies up to 1.5 MHz, and provides 5-mV/A temperature-compensated on-chip current sensing. It targets multi-phase CPU/GPU/DDR voltage-regulator rails in servers, edge/AI systems and telecom infrastructure.
Key specifications
| Part number | TDA21472 |
| Manufacturer | Infineon Technologies |
| Device type | Power Management - Integrated Power Stage (DrMOS / Smart Power Stage) |
| Package | IQFN-39 |
| Package size | 5.00 x 6.00 x 1.00 mm |
| Stock | 20,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Device Type | Integrated Power Stage (DrMOS: gate driver + Schottky diode + HS/LS MOSFETs) |
| Output Current (continuous) | 70 A |
| Output Over-Current Protection (OCP) | 80 A |
| Input Voltage (VIN) Range | 4.25 V to 16 V |
| VCC / VDRV Supply | 4.25 V to 5.5 V |
| Output Voltage Range | 0.25 V to 5.5 V |
| Switching Frequency | 100 kHz to 1500 kHz (up to 1.5 MHz) |
| On-chip Current Sense | 5 mV/A (temperature compensated) |
| Temperature Telemetry Output | 8 mV/C analog |
| PWM Input | 3.3 V tri-state compatible |
| Operating Temperature Range | -40C to +125C |
| Package | PQFN 5 x 6 x 1 mm (Infineon PG-IQFN-39) |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 20,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray or tube as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for TDA21472? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Power Management Chips collection for more Integrated Power Stage devices, or request a quote for TDA21472.
Frequently asked questions
Is TDA21472 original and genuine?
Yes. We supply TDA21472 as original, unused stock sourced through long-verified, traceable channels. Traceability documents, inspection reports and photos of the actual goods can be provided on request before you commit.
How much TDA21472 stock do you have?
20,000 pcs of TDA21472 are currently listed. Stock moves daily - send us your required quantity and we will confirm live availability, date code and lead time.
What package does TDA21472 use?
TDA21472 is supplied in a IQFN-39 package (5.00 x 6.00 x 1.00 mm). Always confirm the package, pinout and thermal pad layout against the current manufacturer datasheet before design-in.
Can you help confirm the TDA21472 parameters?
Yes. Tell us the parameters you are qualifying (supply voltage, current rating, frequency, interface, temperature range or package) and our team will help you confirm them against the current manufacturer datasheet. We do not host third-party datasheets.
Do you quote volume orders for TDA21472?
Yes. We quote volume pricing, available quantity and lead time within 2 working hours, and we can consolidate TDA21472 with other line items into a single shipment.
All trademarks, brand names and part numbers are the property of their respective owners. JTDZ Tech is an independent distributor and is not an authorised distributor, franchisee or agent of the manufacturers named above.
