VN7016AJEPTR STMicroelectronics High-Side Gate Driver PowerSSO-16 | JTDZ Tech
VN7016AJEPTR — Overview
VN7016AJEPTR by STMicroelectronics is a component in the Automotive High-Side Gate Driver (single-channel smart high-side driver with MultiSense analog feedback) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The VN7016AJEPTR is a single-channel smart high-side driver from STMicroelectronics, built on ST's VIPower M0-7 technology and housed in a PowerSSO-16 package. It drives 12 V automotive grounded (resistive, inductive and capacitive) loads through a 3 V/5 V CMOS-compatible interface and provides MultiSense analog feedback of load current, supply voltage and chip temperature, plus detection of overload, short-to-ground, short-to-VCC and OFF-state open-load. With a 16 mΩ on-state resistance at 5 A, 77 A current limitation and advanced protections (current limitation, configurable latch-off thermal shutdown, undervoltage shutdown, overvoltage clamp and reverse-battery), it is AEC-Q100 qualified and targeted at automotive loads such as headlamps.
Key specifications
| Part number | VN7016AJEPTR |
| Manufacturer | STMicroelectronics |
| Device type | Automotive High-Side Gate Driver (single-channel smart high-side driver with MultiSense analog feedback) |
| Package | PowerSSO-16 |
| Package size | 4.90 x 6.00 mm |
| Stock | 20,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Function | Single-channel smart high-side driver with MultiSense analog feedback (VIPower M0-7, AEC-Q100) |
| Operating supply voltage (VCC) | 4 V to 28 V |
| Max transient supply voltage (VCCPK) | 40 V (ISO 16750-2, clamped) |
| On-state resistance (RON) | 16 mΩ typ (IOUT = 5 A, 25 °C); 24 mΩ typ at VCC = 4 V; 32 mΩ max at 150 °C |
| Current limitation (ILIMH) | 77 A typ (55-110 A) |
| Standby current | 0.5 µA (max, 25 °C) |
| Supply current (ON-state) | 3 mA typ / 5 mA max |
| Off-state output current | 0.5 µA max (25 °C) |
| Undervoltage shutdown (VUSD) | 4 V |
| Thermal shutdown (TTSD) | 175 °C typ (150-200 °C), configurable latch-off |
| Output clamp voltage | 46 V typ (41-52 V) |
| Turn-on / turn-off delay | td(on) 30 µs typ (10-120 µs); td(off) 50 µs typ (10-100 µs) |
| Interface / diagnostics | 3 V and 5 V CMOS-compatible input; MultiSense analog load-current/voltage/temperature feedback; SEn, SEL0/1, FaultRST pins |
| Operating junction temperature | -40 to +150 °C |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 20,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray or tube as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for VN7016AJEPTR? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Power Management Chips collection for more High-Side Gate Driver devices, or request a quote for VN7016AJEPTR.
