In a switch-mode power supply the rectifier is where a meaningful slice of the loss lives, so the diode you pick has a direct line to efficiency and heat. The A180WA from Diodes Incorporated is a 40 V, 1 A Schottky barrier rectifier — small, cheap, and exactly right for low-voltage conversion and protection.
Why Schottky
The metal-semiconductor junction gives a Schottky a low forward voltage (often well under a volt) and a very fast recovery. In a buck or boost converter that means less heat in the diode and more energy delivered to the load. The price is higher reverse leakage and a lower voltage ceiling than a p-n rectifier, which is why 40 V class parts like this one suit low-voltage rails.
Typical jobs
- Freewheeling diode. Clipping the inductive kick in a switching regulator so the switch and load are protected.
- Reverse-polarity protection. Blocking a wrongly wired supply with a small, predictable drop.
- OR-ing / blocking. Combining or isolating supply paths in a compact design.
The leakage caveat
Reverse leakage rises sharply with temperature. At room temperature it is negligible; in a hot enclosure it can become a real standby loss. Check the curve at your worst-case junction temperature, not the 25 degC number, and give the part enough copper to stay cool.
Around the same supply
| Function | Part | Link |
|---|---|---|
| Rectification (this part) | Schottky 40 V 1 A | A180WA |
| Switching | 600 V IGBT | HGTG30N60A4 |
| Load switch | Integrated switch | WPM2005-8/TR |
We stock the A180WA and a broad set of power parts; browse the power management range or send us your voltage and current for a quote.
