A fixed RF attenuator is one of those parts engineers reach for constantly yet rarely plan around: it protects receivers, sets repeatable test levels, and tames mismatched sources. The TS0310W3F is a 3 dB fixed attenuator covering DC to 3 GHz — a small, dependable building block for RF benches and products alike.
Why attenuate on purpose
Reducing power sounds like the opposite of what an RF designer wants, but it is often the right move:
- Receiver protection. A strong nearby transmitter or a mis-set generator can overload a front-end. A pad at the input keeps it safe.
- Repeatable test levels. A known attenuation turns a variable generator into a calibrated source.
- Better match. Padding a poorly matched generator improves the effective return loss of the whole setup.
Reading the specs
The TS0310W3F is a 3 dB pad (it halves power) that stays flat from DC to 3 GHz and handles a few watts. Flatness across the band and a low VSWR are what make it trustworthy in a measurement chain rather than just a resistor network.
Related RF building blocks
| Part | Role | Link |
|---|---|---|
| TS0310W3F | 3 dB fixed attenuator | TS0310W3F |
| MCA1-60+ | 60 dB fixed attenuator | MCA1-60+ |
| HFCG-3800+ | Coaxial filter | HFCG-3800+ |
| SAFSF1G44AA0T00R12 | SAW filter | SAFSF1G44AA0T00R12 |
We stock the TS0310W3F and a wide set of RF passives and filters; browse the interface and RF chip range or ask for a quote on the attenuation and connector you need.
