At DC, a 10 pF capacitor is a 10 pF capacitor. At 900 MHz it might be anything. The difference between a working RF match and a detuned one often comes down to using a capacitor that is specified for the frequency. The 600S100JW250XT5 from ATC is a 10 pF, 250 V RF/microwave capacitor in an 0603 body — the kind of part that keeps a high-frequency circuit honest.
The problem with ordinary MLCCs at RF
A standard multilayer ceramic capacitor carries equivalent series inductance and resistance that grow with frequency, and a class II dielectric whose value shifts with voltage and temperature. Above a few hundred MHz the part stops acting like the capacitance on the label, which slowly detunes matching networks and filters. RF-grade parts are specified to avoid exactly this.
What the 600S gives you
- Stable value. NP0/C0G-class dielectric holds its capacitance across temperature and bias.
- Low loss. Ultra-low ESR and high Q mean it does not waste signal or heat at frequency.
- Voltage rating. 250 V in a tiny 0603 body supports RF swing that would destroy a commodity part.
Where it is used
| Use | Why this part | Companion |
|---|---|---|
| Matching network | Stable reactance at frequency | MCA1-60+ attenuator |
| DC block | Passes RF, stops bias | JP503SR coupler |
| Coupling / tuning | Low loss, predictable | 600S100JW250XT5 |
We stock the 600S100JW250XT5 and other RF passives; browse the interface and RF chip range or send us your capacitance, voltage and package for a quote.
