Every board needs at least one clean power rail, and for low-current, low-noise rails a linear regulator is often the simplest answer. The COS2991S is a low-dropout linear regulator from COSINE (科山芯创) supplied in a TO-263-5 package, and it is a common pick where designers want a quiet rail with minimal external parts. This guide covers how to judge an LDO, when it beats a switching regulator, and what to verify before design-in.
How a linear regulator behaves
A linear regulator holds its output constant by controlling a pass element that sits in series with the load. Because the pass element drops the difference between input and output, the part dissipates (Vin − Vout) × Iload as heat. That single relationship drives most of the design decisions: keep the input-output difference and the current small enough that the package can get rid of the heat, and add a small input and output capacitor for stability.
The four numbers that matter
- Dropout voltage — the headroom needed to stay in regulation. Lower is better when you run from a supply that is close to the output voltage or from a discharging battery.
- Quiescent current — the current the regulator consumes with no load. It sets the floor on standby power in always-on designs.
- PSRR / output noise — how well the part rejects input ripple and how much noise it adds. This is the main reason to choose an LDO for an analogue or RF rail.
- Thermal resistance — the package's ability to move heat into the board. This is what actually limits the current you can pass in a given design.
LDO or switching regulator?
Use an LDO when the load current is modest, the input-output difference is small, and a quiet rail matters — sensor front ends, PLL/VCO supplies, audio, and low-power MCU rails. Switch to a buck when the current climbs past roughly half an amp or the input-output difference is large, because the LDO's losses become a thermal problem rather than a rounding error. Many designs use both: a switching pre-regulator followed by an LDO for the noise-sensitive rail.
What to verify before design-in
- Dropout at your real current — the headline figure is often quoted at a fraction of the maximum current.
- Thermal budget — compute the dissipation and compare it with the package's thermal resistance and your copper area.
- Capacitor stability range — most LDOs need an output capacitor within a specified ESR and capacitance range; check it rather than assuming.
- Package and pinout — confirm the footprint against your layout before substituting any part number.
Regulators and support parts we stock
| Part | Function | Package | Link |
|---|---|---|---|
| COS2991S | Low-dropout linear regulator (COSINE) | TO-263-5 | COS2991S |
| COSN6505C | Transformer driver for isolated supplies (COSINE) | SOP | COSN6505C |
Browse the power-management range. Because prices move with quantity and market, send your input/output voltage, current and package for a real-time quote.
Frequently asked questions
What does 'low dropout' actually mean?
Dropout is the minimum input-to-output voltage difference the regulator needs to stay in regulation. A low-dropout (LDO) part keeps that headroom small, so you can run a rail from a supply that is only slightly higher than the output, or hold regulation as a battery discharges. Check the dropout figure against the output current you actually need; dropout is usually specified at a specific current.
When should I use an LDO instead of a switching regulator?
Use an LDO when the current is modest, the input-to-output difference is small, and you need a quiet rail with no switching ripple. Above roughly half an amp, or with a large input-output difference, a switching regulator is usually more efficient because the LDO burns the excess voltage as heat. The decision is really about noise, thermal budget and board area.
What thermal issues should I check?
An LDO dissipates (Vin - Vout) times the load current as heat. Before design-in, confirm the package's thermal resistance, the copper area you can give it, and the worst-case ambient. If the dissipation is marginal, look at a larger package such as a TO-263 and consider the thermal path to the board.
Do you supply COS2991S and similar COSINE regulators?
Yes. We stock the COS2991S from COSINE along with the rest of the COSINE power and signal-chain lines, and we can quote by quantity with date codes so you can validate before committing to volume.
