COSINE Instrumentation and Current-Sense Amplifiers: Bridge and Shunt Front Ends

Precision measurement lives or dies at the front end. A bridge sensor, a thermocouple or a current shunt all produce a tiny differential signal on top of a large common-mode voltage, and the part that recovers it is an instrumentation or current-sense amplifier. This guide covers the COSINE (科山芯创) instrumentation and current-sense amplifiers we stock.

1. Precision instrumentation amplifiers

Instrumentation amplifiers give high common-mode rejection and a clean, fixed gain for differential sensors.

2. Current-sense amplifiers

Current sensing needs a part that tolerates the shunt common-mode voltage and amplifies the small drop accurately.

Selection checklist

• Define the common-mode voltage range first — it eliminates most candidates.
• Set the gain from your shunt drop and the ADC full-scale.
• Check offset and drift against the signal you must resolve.
• Confirm the input range survives the maximum bus voltage.

See the wider amplifiers range. Send us your common-mode range, gain and package for a quote.

Frequently asked questions

What is an instrumentation amplifier used for?

An instrumentation amplifier amplifies a small differential signal sitting on a large common-mode voltage — exactly the situation at a bridge sensor, a current shunt or a remote transducer. Its high common-mode rejection and fixed gain make it the standard front end for precision measurement.

How does a current-sense amplifier work?

A current-sense amplifier measures the small voltage across a shunt resistor and presents a larger, ground-referenced output. It must tolerate the shunt's common-mode voltage, which can be near the supply rail, so its input range matters as much as its gain.

Why use a dedicated current-sense amplifier instead of an op-amp?

A dedicated part is built for the high common-mode range and the small differential signal at the shunt, with the gain set internally. An op-amp can do it, but you must design the common-mode handling and gain yourself, which is easy to get wrong near the rail.

Are these COSINE parts drop-in replacements?

They are designed against the pinout and function of the referenced devices. Confirm package, pinout and electrical limits on the datasheet for your application before volume commitment.
