Switching power efficiently is mostly about driving the gate fast and cleanly. Too little gate current and the MOSFET lingers in its linear region, heating up; too much and you add ringing and EMI. This guide covers MOSFET gate drivers and 600 V high-voltage drivers from COSINE (科山芯创) we stock.
1. MOSFET gate drivers
These buffers supply the peak current the gate needs, with defined logic thresholds and drive strength.
| Part | Notes | Link |
|---|---|---|
| COS4422SR (TC4422) | MOSFET gate driver, dual | COS4422SR (TC4422) |
| COS4421SR (TC4421) | MOSFET gate driver | COS4421SR (TC4421) |
| COS3122SR (FAN3122) | MOSFET gate driver | COS3122SR (FAN3122) |
| COS27425SR (TC4425) | MOSFET gate driver, dual | COS27425SR (TC4425) |
2. 600 V high-voltage gate drivers
Half-bridge and full-bridge supplies need a high-side driver with a bootstrap supply. These parts cover the 600 V class.
| Part | Notes | Link |
|---|---|---|
| COS2184S (IRS2184) | 600 V half-bridge gate driver | COS2184S (IRS2184) |
| COS21844S (IRS21844) | 600 V high-voltage gate driver | COS21844S (IRS21844) |
| COS2113PBF (IRS2113) | 600 V half-bridge gate driver | COS2113PBF (IRS2113) |
Selection checklist
- Calculate gate charge and your target switching time to size peak current.
- Decide low-side versus half-bridge from the topology.
- Confirm the driver supply and input logic match your controller.
- Check the bootstrap capacitor and dead-time handling in your layout.
See the wider power management range. Send us your topology, voltage and package for a quote.
Frequently asked questions
Why do I need a MOSFET gate driver at all?
A MOSFET gate is a capacitor. To switch quickly you must move charge into and out of it fast, and a microcontroller pin cannot. A gate driver is a buffer that supplies the peak current, so the MOSFET spends as little time as possible in its linear region, which limits switching loss and heat.
What is the difference between a low-side and a half-bridge driver?
A low-side driver switches an N-channel MOSFET to ground. A half-bridge (high-side/low-side) driver switches a high-side MOSFET whose gate must be driven above the supply, which needs a bootstrap or charge-pump supply that IRS2184 and IRS2113 class devices integrate.
How much peak current do I need from the driver?
Divide the gate charge by your desired rise time to get the average current, then choose a driver with peak rating comfortably above that. Under-driving the gate causes slow switching and extra loss; over-driving can stress the gate.
Are these COSINE parts drop-in replacements?
They are designed against the pinout and function of the referenced devices. Confirm package, pinout and voltage ratings on the datasheet for your application before volume commitment.
