Power management is where a design either runs quietly or fails intermittently. The three blocks most often requested are low-dropout regulators, precision voltage references and PWM controllers — and COSINE (科山芯创) offers alternatives for each. This guide covers how to choose and the parts we stock.
1. Low-dropout linear regulators
An LDO trades efficiency for simplicity, low noise and low cost. It remains the right answer for noise-sensitive analogue rails and small drops.
| Part | Notes | Link |
|---|---|---|
| COS29502WU (MIC29502) | Low-dropout linear regulator | COS29502WU (MIC29502) |
| COS29302WU (MIC29302) | Low-dropout linear regulator | COS29302WU (MIC29302) |
| COS2991S | Low-dropout linear regulator, original COSINE part | COS2991S |
2. Voltage references
For ADCs, DACs and comparators, the reference decides the absolute accuracy of the whole conversion.
| Part | Notes | Link |
|---|---|---|
| COSTLVH431A (TLVH431) | Voltage reference | COSTLVH431A (TLVH431) |
| COSTLVH432A (TLVH432) | Voltage reference | COSTLVH432A (TLVH432) |
3. PWM controllers
For off-line and isolated supplies, a current-mode PWM controller is still the practical core.
| Part | Notes | Link |
|---|---|---|
| COS3842BD (UC3842) | Current-mode PWM controller | COS3842BD (UC3842) |
| COS3525ADW (SG3525) | PWM controller | COS3525ADW (SG3525) |
Selection checklist
- Define input range, output and load current before choosing a regulator.
- For references, check initial accuracy and drift against your converter resolution.
- Size the PWM controller's sense resistor and transformer for your power level.
- Confirm package and pinout against the referenced device before volume build.
See the wider power management range and amplifiers range. Send us your input, output and package for a quote.
Frequently asked questions
What does 'low dropout' actually mean?
Dropout is the minimum input-to-output difference at which the regulator still regulates. A lower dropout lets you run from a supply closer to your output, which improves efficiency and extends battery life. The cost is a smaller headroom margin for load transients.
When do I use a voltage reference instead of a regulator?
A voltage reference sets a precise, stable voltage for an ADC, DAC or comparator, where absolute accuracy and drift matter more than load current. A regulator supplies a rail. Use a reference where the spec is the voltage itself, not the power.
Why are current-mode PWM controllers still common?
Current-mode control gives simpler compensation and good line rejection for off-line and isolated supplies, which is why UC3842 and SG3525 class controllers remain the backbone of many power designs. They are mature, well documented and widely second-sourced.
Are these COSINE parts drop-in replacements?
They are designed against the pinout and function of the referenced devices. Confirm package, pinout and electrical limits on the datasheet for your application before volume commitment.
