Plenty of products ship with a serial port as their service interface, and plenty of microcontrollers have no USB peripheral at all. The FT232RL from FTDI bridges the two: it turns USB into an ordinary UART so the board appears as a virtual COM port on a host PC. This guide covers where a bridge chip is the right call, how the on-chip configuration works, and what to verify before design-in.
Why a dedicated bridge
A USB-to-UART bridge lets your application firmware stay focused on the product and treat the host link as a simple serial port. The device handles USB enumeration, the serial protocol and the driver side, and the host sees a COM port through the standard virtual COM port driver or the vendor's own driver. That separation is valuable in test equipment, industrial controllers and any design where the USB link must keep working even when the application firmware is being updated.
What to check
- Supply and I/O levels — confirm the bridge can run from the rail you have and drive the logic level your MCU uses.
- Configurable identifiers — the on-chip memory stores the device's USB identifiers and serial string, which is how each board gets a unique identity.
- Baud range — make sure the rates you need are covered with margin.
- Driver support — check the host operating systems your customers will use, since deployment without a working driver is a support burden.
Bridge or native USB?
A bridge wins when you want the serial link independent of the application, when you are adding USB to an existing UART design, or when the firmware team would rather not implement a USB stack. Native USB in the MCU wins when you need a custom device class, a composite device, or the lowest possible part count. It is a normal engineering trade, and many designs reasonably use a bridge for the service port while the main MCU handles the rest.
Interface parts we stock
| Part | Function | Package | Link |
|---|---|---|---|
| FT232RL | USB 2.0 to UART / FIFO bridge (FTDI) | SSOP-28 | FT232RL |
| MAX3232CSE | RS-232 transceiver (Maxim / ADI) | SOIC-16 | MAX3232CSE |
| MAX232CPE | RS-232 transceiver (Maxim / ADI) | DIP-16 | MAX232CPE |
| MAX485ESA | RS-485 / RS-422 transceiver (Maxim / ADI) | SOP-8 | MAX485ESA |
Explore the interface and RF chip range. Send your interface type, package and quantity for a quote.
Frequently asked questions
What does a USB-to-UART bridge do?
It converts USB into a plain serial UART, so a microcontroller that has no USB peripheral can still appear as a virtual COM port on a PC. The bridge handles the USB protocol and the enumeration; your firmware only sees a familiar UART, which is why these parts are so common on development and test hardware.
What is the internal EEPROM for?
The bridge stores configuration in on-chip memory: the USB vendor and product identifiers, the serial number string and various interface settings. Because the identifiers are programmable, each board can present a unique serial number, which lets a host tell one unit from another on the same machine.
How do I choose between a bridge chip and an MCU with built-in USB?
Use a dedicated bridge when you want the serial link to be completely independent of your application firmware, or when you are adding USB to an existing UART design. Choose an MCU with native USB when you want to implement a custom class or avoid the extra device. Both are legitimate; the decision is about firmware complexity and board cost.
Do you stock FT232RL and similar interface bridges?
Yes. We stock the FT232RL together with UART and line-driver parts such as the MAX3232 and MAX485 families, and we can quote by quantity with date codes so you can validate before committing to volume.
Recommended next steps
If you are sourcing any of the parts mentioned in this guide, we can help you confirm stock, pricing, and lead times quickly.
- Upload your BOM — send your full parts list and receive a consolidated quote within 2 business hours.
- Browse related in-stock lines: Interface / RF Chips.
- Contact our team for hard-to-find or end-of-life components.
