Global navigation satellite systems turned positioning into a utility. But a GNSS receiver is one of the hardest radios to design, because it spends its life trying to hear a signal that is billions of times weaker than the noise and interference around it. Every decibel of noise figure and every tenth of a dB of filter rejection is paid for directly in time-to-fix and positioning accuracy.
The receive-only challenge
Unlike a phone or a Wi-Fi link, a GNSS receiver almost never transmits. It only listens, on L-band signals around 1.5 GHz, arriving at roughly -130 dBm. There is no transmit power to fall back on, so the entire design budget is spent on receive sensitivity. The first amplifier after the antenna — or inside it — sets the noise floor of the whole system.
We stock low-noise and gain-block amplifiers such as the TQP3M9019, the SGA-6389Z, the ERA-1SM+ and the GALI-21+, which are commonly referenced where a low-power, low-noise receive or driver stage is needed.
Filtering is the make-or-break step
The same device that receives GNSS almost always also transmits on cellular or Wi-Fi, often at power levels a hundred million times stronger than the satellite signal. A sharp filter rejects that energy before it overloads the receiver. We stock LC filter families such as the LFCN-3800+ low-pass and HFCN-5500+ high-pass filters for this front-end conditioning.
Switching and level
A switch may select between active and passive antennas or between bands, and an attenuator trims level so a strong signal does not compress the chain. We supply switches such as the QPC6044TR13 and the AS179-92LF SPDT switch, and step attenuators like the PE4302-52 plus fixed pads such as the ATN3580-02.
Sourcing for positioning products
GNSS modules go into everything from asset trackers to survey gear, often in high volume. A single constrained low-noise amplifier or filter can ripple through the bill of materials. We help by supplying the RF discretes from traceable sources and finding alternatives when a part is allocated. Browse the RF and interface chip range and the Mini-Circuits collection for related devices.
Frequently asked questions
What RF parts does a GNSS receiver use?
A GNSS receiver listens for very weak satellite signals across the L-band (GPS L1, Galileo E1, BeiDou B1 and similar). The chain is a low-noise amplifier right at the antenna or just behind it, a filter to reject nearby cellular and LTE energy, a switch for antenna or band selection, and gain blocks to lift the signal to the chipset. Sensitivity is everything.
Why is filtering so important in GNSS?
GNSS signals arrive at roughly -130 dBm, far below the noise floor of a cellular transmitter sitting centimetres away in the same device. Without a sharp filter rejecting the cellular and LTE bands, the receiver is overwhelmed. The filter and the first low-noise amplifier decide whether a fix is fast and reliable or impossible.
What specifications matter for a GNSS LNA?
Noise figure dominates, because the LNA sets the receiver's noise floor. Gain must be enough to bury downstream noise, but not so much that strong signals compress. Linearity (OIP3) matters in crowded urban spectra where interferers create intermodulation on the wanted signal.
Can you supply GNSS-relevant RF parts?
Yes. We stock low-noise and gain-block amplifiers, RF switches, filters and step attenuators commonly referenced in GPS, GNSS and BeiDou receiver front ends, from traceable sources with date-code verification. Send your part list and quantity for a quote.
