RF Amplifier and Gain Block Selection Guide: Gain, Noise Figure and P1dB

Amplifier selection is where noise figure, gain, linearity and power handling stop being abstract numbers and start deciding whether the product works. The good news is that most designs need only a handful of well-understood parts. This guide covers gain blocks, low-noise amplifiers and power amplifiers, and the parts we stock across those roles.

1. Place the amplifier by its job

Decide where the part sits before comparing datasheets. The position determines which specification dominates.

• First stage after the antenna — noise figure dominates; use a low-noise part.
• Mid-chain loss recovery — flat gain and simplicity dominate; use a gain block.
• Final transmit stage — output power, efficiency and linearity dominate; use a power amplifier.

2. Gain blocks and general-purpose amplifiers

Gain blocks are internally matched, broadband and need few external components. They are the fastest way to recover loss from a filter, mixer or long trace.

3. Low-noise and driver amplifiers

Where the incoming signal is small, noise figure decides the sensitivity of the whole receiver. These parts are commonly evaluated for front-end and driver roles.

4. Power amplifiers for the transmit path

Power amplifiers are specified by output power, efficiency and linearity. Check the expected peak-to-average ratio of your modulation and leave headroom below P1dB.

Selection checklist

• Fix the role first: low-noise, general gain, or power output.
• Check gain, noise figure and P1dB over your actual band, not just at one frequency.
• Confirm supply voltage and current against your power budget.
• Leave headroom below compression for modulated signals.
• Verify stability and layout requirements — RF amplifiers are layout sensitive.

Browse the wider RF amplifier and interface range. Send us your band, gain and output requirement for a real-time quote.

Frequently asked questions

What is the difference between a low-noise amplifier and a power amplifier?

A low-noise amplifier is optimised to add as little noise as possible while providing modest gain, and it sits at the very front of a receiver. A power amplifier is optimised to deliver output power into a load with acceptable efficiency and linearity, and it sits at the end of a transmit chain. Using one in place of the other gives poor results in both directions.

What does P1dB mean and why does it matter?

P1dB is the output power at which the amplifier's gain has compressed by 1 dB from its small-signal value. Operating beyond it distorts the signal and, for modulated signals, produces spectral regrowth that can fail compliance. Keep your expected peak output comfortably below P1dB.

What is a gain block and when is it the right choice?

A gain block is a general-purpose, internally matched amplifier that gives a predictable amount of gain over a broad band with very few external parts. It is the right choice when you need to make up loss in a cable, filter or mixer rather than optimise for the lowest possible noise or the highest possible output power.

How much gain should I put in one stage?

Resist putting all the gain in one place. Very high gain in a single stage invites instability, sensitivity to layout and compression. Splitting gain across stages with filtering between them usually gives better stability and better spurious performance.
