Two small diodes are usually what stand between a receiver and a damaged front end. PIN diodes give you controllable RF resistance for switching and attenuation; limiter diodes give you automatic protection against a large incoming signal. Both are simple to describe and easy to specify incorrectly. This guide covers the families we stock and how to choose between them.
1. PIN diodes for switching and attenuation
The useful property of a PIN diode is that its RF resistance is set by DC bias current, while its capacitance stays low when it is off. That makes it a variable resistor at RF, which is the basis of both series/shunt switches and current-controlled attenuators.
| Part | Notes | Link |
|---|---|---|
| HSMP-3866-TR1G | PIN diode for RF switching and attenuation | HSMP-3866-TR1G |
| HSMP-3860-TR1G | PIN diode for RF switching | HSMP-3860-TR1G |
| HSMP-3813-TR1G | PIN diode, general RF use | HSMP-3813-TR1G |
| HSMP-3814-TR1G | PIN diode, general RF use | HSMP-3814-TR1G |
| HSMP-3820-TR1G | PIN diode, general RF use | HSMP-3820-TR1G |
| SMP1322-005LF | PIN diode for switching and attenuator designs | SMP1322-005LF |
| MA4P7435NM-1091T | PIN diode for higher-power switching | MA4P7435NM-1091T |
| MA4P161-134 | PIN diode for RF switching | MA4P161-134 |
| MA4P404-132 | PIN diode for RF switching | MA4P404-132 |
2. Limiter diodes for receiver protection
A limiter sits ahead of the low-noise amplifier and clamps large signals. Choose it by limiting threshold, small-signal insertion loss and — most importantly — the leakage that still passes through under a large input.
| Part | Notes | Link |
|---|---|---|
| MA4L021-134 | Limiter diode for receiver protection | MA4L021-134 |
| MA4L011-134 | Limiter diode for receiver protection | MA4L011-134 |
| MADL-011008-14120T | Limiter diode, integrated style | MADL-011008-14120T |
| MADL-011021-14150T | Limiter diode, integrated style | MADL-011021-14150T |
3. PIN diode arrays and integrated limiter/pin functions
Integrated parts reduce component count and board area and are often easier to reproduce across builds than a discrete diode network with hand-tuned matching.
| Part | Notes | Link |
|---|---|---|
| MADP-000907-14020P | PIN/limiter diode function | MADP-000907-14020P |
| MADP-011037-13900T | PIN/limiter diode function | MADP-011037-13900T |
| MA4E1317 | Diode device for RF control | MA4E1317 |
| MA4AGBLP912 | RF control diode / device | MA4AGBLP912 |
Selection checklist
- Decide discrete PIN versus integrated switch IC based on power, frequency and board area.
- For limiters, check leakage power first — that is what protects the next stage.
- Confirm bias requirements and whether you need a bias network on the board.
- Match the package and orientation to your assembly process.
- Verify behaviour across temperature if the product sees a wide range.
Browse the wider RF diode and interface range. Send us your frequency, power level and package for a real-time quote.
Frequently asked questions
What is a PIN diode used for in an RF design?
A PIN diode has a thick intrinsic region between its p and n layers, which makes its RF resistance depend on the DC current flowing through it. That property is used to build RF switches and attenuators: forward bias gives low resistance, and reverse or zero bias gives high resistance with low capacitance.
What does a limiter diode do?
A limiter diode protects a sensitive receiver input by becoming conductive when the incoming signal is large, effectively shunting the excess energy away. It sits ahead of the low-noise amplifier and is the standard way to survive a nearby transmitter or an accidental overdrive condition.
How do I choose between a PIN diode and a RF switch IC?
Discrete PIN diodes are flexible, handle high power and can be tuned for a specific frequency with external matching, but they need bias networks and more board area. An RF switch IC integrates the switching element and control logic, is much easier to lay out, and is usually the better choice below a few GHz and at moderate power levels.
What specifications matter most for a limiter?
The key numbers are the threshold or limiting level, the insertion loss in the small-signal state, the leakage or flat leakage power that still reaches the following stage, and the power handling. Check leakage especially — that is what determines whether the following low-noise amplifier survives.
