RF Switch Selection Guide: Insertion Loss, Isolation and Switching Speed

An RF switch looks like a trivial part until you discover that its insertion loss is eating your link budget, or that its isolation is letting a transmitter leak into a receiver. This guide covers the specifications that matter and the switch parts we stock across the common frequency bands and control interfaces.

1. The four numbers that decide the part

• Insertion loss — added directly to receiver noise figure; lower is better.
• Isolation — how much of the off path still gets through; higher is better.
• P1dB / power handling — sets how much signal the switch can pass without compressing.
• Switching speed — matters in time-division and multiplexed paths.

2. Absorptive and reflective switches

If the stage before the switch is sensitive to a changing load, choose an absorptive part. If the source is well isolated or the mismatch is tolerable, a reflective part is simpler and usually lower loss.

3. RF switches we stock

Selection checklist

• Confirm the frequency band and that insertion loss is specified across it.
• Check isolation at the frequency that matters, not just at a headline value.
• Decide absorptive versus reflective from what the switch is driving and being driven by.
• Verify control logic levels and the required switching time.
• Leave power headroom below the specified compression point.

Browse the wider RF switch and interface range. Send us your band, topology and control interface for a real-time quote.

Frequently asked questions

What is the difference between insertion loss and isolation in an RF switch?

Insertion loss is how much signal the switch attenuates in its on state, and it adds directly to the noise figure of a receiver chain. Isolation is how much signal leaks through in the off state, and it determines how much of an unwanted path still reaches the output. Low insertion loss and high isolation are both desirable and usually trade against each other.

How fast does an RF switch need to be?

It depends entirely on the application. A band-selection switch that changes on power-up can be slow, while a switch in a time-division transmit/receive path must settle within the switching slot. Check the specified switching time and the settling behaviour, and remember that the control interface adds its own delay.

What is an absorptive versus a reflective RF switch?

A reflective switch presents an open or short in the off state, so energy is reflected back toward the source, which can disturb a preceding stage. An absorptive switch terminates the off path in its characteristic impedance, which keeps the source matched. Absorptive parts are preferred when the preceding stage is sensitive to mismatch.

Can I use a general-purpose analogue switch for RF?

Only at low frequency and with modest performance expectations. RF switches are designed for controlled impedance, low capacitance and specified isolation across a defined band. A general-purpose analogue switch has no defined RF impedance and its loss and isolation vary unpredictably with frequency.
