AG102-G — Overview
AG102-G by Qorvo is a component in the 60-3000 MHz General-Purpose Gain Block category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The AG102-G is a general-purpose GaAs MMIC gain block that combines near-constant OIP3 with a low 2.4 dB noise figure across 60 to 3000 MHz. It is internally matched to 50 ohm, needs only DC-blocking/bypass capacitors and an RF choke, and is supplied in a lead-free SOT-89 package. The device is now obsolete, available from independent stock.
Key specifications
| Part number | AG102-G |
| Manufacturer | Qorvo |
| Device type | GaAs MMIC Gain Block Amplifier |
| Package | SOT-89 |
| Package size | 4.50 x 4.10 x 1.50 mm |
| Stock | 1,500 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Frequency range | 60 to 3000 MHz |
| Gain | 14 dB at 800 MHz (13 to 16 dB) |
| P1dB | +18 dBm |
| OIP3 | +36 dBm |
| Noise figure | 2.4 dB |
| Input return loss | 8.5 dB |
| Output return loss | 20 dB |
| Supply voltage | +4.5 V (or +3.3 V) |
| Supply current | 70 mA (55 to 90 mA) |
| Thermal resistance | 88 °C/W |
| Operating temperature | -40 to +85 °C |
| MTTF | > 1000 years at +85 °C |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: Discontinued by Qorvo (no replacement listed); now obsolete, available from independent stock. P1dB is +18 dBm typical per the TriQuint/WJ datasheet (some distributor listings quote 15 dBm).
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 1,500 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray, tube or bulk as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for AG102-G? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Interface Chips / RF Chips collection for more Gain Block Amplifier devices, or request a quote for AG102-G.
Other Qorvo parts in stock
| SZM-3166Z | SGA5589Z | RFFM8209TR |
| AH225-S8G | RF6525SR | RFSA3713TR7 |
Frequently asked questions
Is AG102-G original and genuine?
Yes. We supply AG102-G as original, unused stock sourced through long-verified, traceable channels. Traceability documents, inspection reports and photos of the actual goods can be provided on request before you commit.
How much AG102-G stock do you have?
1,500 pcs of AG102-G are currently listed. Stock moves daily - send us your required quantity and we will confirm live availability, date code and lead time.
What package does AG102-G use?
AG102-G is supplied in a SOT-89 package (4.50 x 4.10 x 1.50 mm). Always confirm the package, pinout and land pattern against the current manufacturer datasheet before design-in.
Can you help confirm the AG102-G parameters?
Yes. Tell us the parameters you are qualifying (frequency range, gain, attenuation, voltage, current or temperature range) and our team will help you confirm them against the current manufacturer datasheet. We do not host third-party datasheets.
Do you quote volume orders for AG102-G?
Yes. We quote volume pricing, available quantity and lead time within 2 working hours, and we can consolidate AG102-G with other line items into a single shipment.
All trademarks, brand names and part numbers are the property of their respective owners. JTDZ Tech is an independent distributor and is not an authorised distributor, franchisee or agent of the manufacturers named above.
