F5AHC4100ZAA6M — Overview
F5AHC4100ZAA6M by KEMET is a component in the EMI/RFI Suppression Film Capacitor + Varistor (1.0 uF, 25 VDC, radial) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The F5AHC4100ZAA6M is a KEMET F5A series low-voltage transient suppression component: a 1.0 uF metallized polyester (MKT) film capacitor connected in parallel with a 33 V multilayer ceramic varistor inside one radial plastic box. It is rated 25 VDC, +/-20%, has 5 mm lead spacing and is qualified to AEC-Q200 and ISO 7637 for automotive motor and EMI/RFI suppression. It is a film capacitor (not ceramic, not aluminium electrolytic).
Key specifications
| Part number | F5AHC4100ZAA6M |
| Manufacturer | KEMET |
| Device type | Metallized Polyester Film Capacitor with Integrated Ceramic Varistor |
| Package | Radial |
| Package size | 7.4 x 5.1 x 10.1 mm (L x T x H), 5.0 mm pitch |
| Stock | 5,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Capacitance | 1.0 uF (code 4100 = 100 pF x 10^4) |
| Tolerance | +/-20% (code M) |
| Rated voltage | 25 VDC (code H) |
| Dielectric | Metallized polyester film (MKT), non-polarized |
| Integrated varistor | Multilayer ceramic varistor, EIA 1206, Vv = 33 VDC (code A) |
| Clamping voltage | 54 V @ 1 A, 8/20 us pulse |
| Capacitance range (series) | 0.1 - 2.2 uF |
| Dissipation factor | 0.01 max (1 kHz, 25 C) |
| Leakage current | <= 50 uA at rated voltage |
| Insulation resistance | 1 MOhm min (measured at 24 V for VR >= 24 V) |
| Peak current, 8/20 us | 200 A (for Vv < 50 V) |
| Operating temperature | -55 C to +125 C |
| Climatic category | 55/125/56 (IEC 60068-1) |
| Approvals | AEC-Q200, ISO 7637 |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: Series verified as metallized polyester film (MKT) with integrated ceramic varistor, not a plain ceramic or electrolytic capacitor. Capacitance code 4100 decodes to 1.0 uF (100 pF x 10^4), consistent with the 0.1-2.2 uF series range. The lead/packaging code 'ZA' is not listed in the current KEMET ordering table (AA, DQ, Z3, CK) - confirm packaging/lead length with KEMET.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 5,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray, tube or bulk as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for F5AHC4100ZAA6M? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Other Chips collection for more Film Capacitor with Varistor devices, or request a quote for F5AHC4100ZAA6M.
Frequently asked questions
Is F5AHC4100ZAA6M original and genuine?
Yes. We supply F5AHC4100ZAA6M as original, unused stock sourced through long-verified, traceable channels. Traceability documents, inspection reports and photos of the actual goods can be provided on request before you commit.
How much F5AHC4100ZAA6M stock do you have?
5,000 pcs of F5AHC4100ZAA6M are currently listed. Stock moves daily - send us your required quantity and we will confirm live availability, date code and lead time.
What package does F5AHC4100ZAA6M use?
F5AHC4100ZAA6M is supplied in a Radial package (7.4 x 5.1 x 10.1 mm (L x T x H), 5.0 mm pitch). Always confirm the package, pinout and land pattern against the current manufacturer datasheet before design-in.
Can you help confirm the F5AHC4100ZAA6M parameters?
Yes. Tell us the parameters you are qualifying (frequency range, gain, attenuation, voltage, current or temperature range) and our team will help you confirm them against the current manufacturer datasheet. We do not host third-party datasheets.
Do you quote volume orders for F5AHC4100ZAA6M?
Yes. We quote volume pricing, available quantity and lead time within 2 working hours, and we can consolidate F5AHC4100ZAA6M with other line items into a single shipment.
All trademarks, brand names and part numbers are the property of their respective owners. JTDZ Tech is an independent distributor and is not an authorised distributor, franchisee or agent of the manufacturers named above.
