G8ND-2UK-12VDC — Overview
G8ND-2UK-12VDC by Omron is a component in the Relays > Automotive Relays > PCB Power Relays category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The G8ND-2UK-12VDC is an Omron automotive PCB power relay containing two SPDT contacts (2 Form C) arranged as an H-bridge for DC motor reversal. It switches 25 A motor loads at 12 VDC with 30 A inrush, driven by a 12 VDC, 130 Ω ultra-low-operate coil, in a fully sealed 8-terminal PCB package rated from -40 to +85 °C.
Key specifications
| Part number | G8ND-2UK-12VDC |
| Manufacturer | Omron |
| Device type | Automotive PCB Power Relay (dual SPDT, H-bridge) |
| Package | DIP-8 |
| Package size | 8-pin PCB mount, 7.5 g, sealed case |
| Stock | 5,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Contact form | 2 Form C (SPDT x 2, internal H-bridge) |
| Rated load | 25 A at 12 VDC (motor load) |
| Inrush current | 30 A |
| Max. switching voltage | 16 VDC |
| Max. carry current | 25 A at 14 VDC (10 min) |
| Coil voltage | 12 VDC |
| Coil resistance | 130 Ω (ultra-low operate) |
| Coil current | 92.3 mA |
| Must operate / release voltage | 5.5 V max / 0.8 V min |
| Operate / release time | 10 ms max / 5 ms max |
| Contact resistance | 50 mΩ max |
| Dielectric strength | 500 VAC for 1 min (coil to contact) |
| Electrical / mechanical life | 100,000 / 1,000,000 operations |
| Operating temperature | -40 to +85 °C |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: Per Omron nomenclature: 2 = two Form C contacts (H-bridge), U = ultra-low operate coil (130 Ω), K = special specification, -12VDC = 12 V coil. Sealed, cadmium-free silver-tin contacts; intended for door locks, power windows, seat adjustment and sunroofs. AEC-Q101 is a semiconductor specification and is not stated for this relay; Omron positions it as an automotive-grade part.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 5,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray, tube or bulk as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for G8ND-2UK-12VDC? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Other Chips collection for more Automotive Power Relay devices, or request a quote for G8ND-2UK-12VDC.
