HCPL-3120-000E — Overview
HCPL-3120-000E by Broadcom is a high-volume electronic component supplied by Shenzhen Jingteng Electronics (JTDZ Tech). 2.5A IGBT gate-drive optocoupler, a common driver for high-power inverters and welders. We keep this part in stock for OEMs, ODMs and EMS providers in India, Vietnam and the Middle East.
Key Specifications
| Part Number | HCPL-3120-000E |
| Manufacturer | Broadcom |
| Category | Interface Chips / RF Chips |
| Package | DIP-8 |
| Pin Count | 8 |
| Output Current | 2.5 A peak |
| Isolation Voltage | 3750 Vrms |
| Supply Voltage | 15 V - 30 V |
| Propagation Delay | 0.7 us max |
| CMR | 15 kV/us minimum |
| UVLO | With under-voltage lockout |
| Operating Temp | -40 °C to +100 °C |
| Package | DIP-8 |
| Date Code | Recent date code, factory |
| Stock Status | In stock — ships within 24 hours |
| Description | Interface Chips / RF Chips, 15 V - 30 V, 2.5 A peak, DIP-8 package. |
Typical Applications
IGBT/MOSFET drives, welding machines, induction cookers, industrial inverters.
Why Buy HCPL-3120-000E from JTDZ Tech
- Verified and new parts, traceable date code, Certificate of Conformance available
- MOQ 1 pc, tier pricing for volume orders
- X-ray and visual inspection, third-party lab test (White Horse / GDS) supported before shipment
- Quote within 2 business hours, export shipping to India, Vietnam, the Middle East and worldwide
