PE3236-54 — Overview
PE3236-54 by pSemi is a component in the PLL Frequency Synthesizer (Integer-N, 2.2 GHz, UltraCMOS) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The PE3236-54 is a 2.2 GHz integer-N PLL synthesizer fabricated on Peregrine's UltraCMOS silicon-on-sapphire process, containing a 10/11 dual-modulus prescaler, 9-bit M and 4-bit A counters, an R reference counter and an internal phase-frequency detector. Counters can be loaded serially, in parallel or hard-wired, and the dual-latch architecture supports ping-pong loading for fractional-N or sigma-delta loops. It operates from a 3.0 V supply at 22 mA typical and is supplied in a green 44-lead PLCC. The device is obsolete.
Key specifications
| Part number | PE3236-54 |
| Manufacturer | pSemi |
| Device type | Integer-N PLL Frequency Synthesizer |
| Package | PLCC-44 |
| Package size | 44-lead PLCC (JEDEC PLCC-44 footprint) |
| Stock | 1,500 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Maximum operating frequency | 2200 MHz |
| Frequency range, prescaler enabled | 200 to 2200 MHz |
| Frequency range, prescaler bypassed | 20 to 220 MHz |
| Prescaler | 10/11 dual modulus |
| Main counter | 9-bit M counter plus 4-bit A counter |
| Phase detector comparison frequency | 20 MHz max |
| Reference input frequency | 100 MHz max |
| Supply voltage VDD | 2.85 to 3.15 V (3.0 V nom) |
| Supply current | 22 mA typ at 3 V (35 mA max) |
| SSB phase noise @ 100 Hz offset | -75 dBc/Hz |
| SSB phase noise @ 1 kHz offset | -85 dBc/Hz |
| RF input power | -5 to +5 dBm |
| Serial clock frequency | 10 MHz max |
| Operating temperature | -40 to +85 °C |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: The '-54' suffix is the ordering code '3236-54' = PE3236G-44PLCC-500C: green 44-lead PLCC, 500 units on tape and reel (other codes: -21 tube, -22 non-green T&R). The datasheet is flagged 'Obsolete' by pSemi, so the part is no longer in production and is available only from independent stock.
