STC3100IQT — Overview
STC3100IQT by STMicroelectronics is a component in the Battery Monitor IC (single-cell Li-Ion coulomb counter / gas gauge) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The STC3100IQT is a battery monitor IC from STMicroelectronics that measures the voltage, temperature and current of a single-cell Li-Ion battery and implements a Coulomb-counter gas gauge using a programmable 12- to 14-bit ADC. With a typical 30 mΩ sense resistor it supports battery currents up to 2.5 A and accumulates up to ±7000 mAh of capacity at 0.2 mAh resolution. Housed in a 3 x 3 mm DFN-8 package, it communicates over an I²C interface and includes an internal temperature sensor, a 32768 Hz time base, 32 bytes of RAM and an 8-byte unique ID, targeting cellular phones, PDAs, MP3 players, digital cameras and other portable devices.
Key specifications
| Part number | STC3100IQT |
| Manufacturer | STMicroelectronics |
| Device type | Battery Monitor IC (single-cell Li-Ion coulomb counter / gas gauge) |
| Package | DFN-8 |
| Package size | 3.00 x 3.00 mm |
| Stock | 20,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Function | Single-cell Li-Ion battery monitor with Coulomb counter / gas gauge |
| Battery chemistry / cells | 1-cell Li-Ion |
| Supply voltage (VCC) | 2.7 V to 5.5 V |
| Operating current | 100 µA (average over 4 s) |
| Standby / power-down current | 2 µA standby; 1 µA power-down |
| Coulomb counter input range | ±80 mV (external sense resistor) |
| ADC resolution | 12 / 13 / 14-bit programmable (47.08 / 23.54 / 11.77 µV per LSB) |
| Current / capacity measurement | up to 2.5 A (30 mΩ sense); ±7000 mAh capacity, 0.2 mAh resolution |
| Time base | Internal or external 32768 Hz |
| Interface | I²C (SDA / SCL) |
| Battery voltage accuracy | ±0.5 % |
| Gas gauge accuracy | 3.5 % (internal time base); 1 % (external time base) |
| Memory / ID / GPIO | 32 bytes RAM; 8-byte unique device ID; 1 general-purpose I/O; internal temperature sensor |
| Operating temperature | -40 to +85 °C |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 20,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray or tube as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for STC3100IQT? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Power Management Chips collection for more Battery Fuel Gauge devices, or request a quote for STC3100IQT.
Other STMicroelectronics parts in stock
| PD84008-E | STMPS2151STR | STM32L063R8T6TR |
| TL431IL5T | L293DD | LIS3DHTR |
Frequently asked questions
Is STC3100IQT original and genuine?
Yes. We supply STC3100IQT as original, unused stock sourced through long-verified, traceable channels. Traceability documents, inspection reports and photos of the actual goods can be provided on request before you commit.
How much STC3100IQT stock do you have?
20,000 pcs of STC3100IQT are currently listed. Stock moves daily - send us your required quantity and we will confirm live availability, date code and lead time.
What package does STC3100IQT use?
STC3100IQT is supplied in a DFN-8 package (3.00 x 3.00 mm). Always confirm the package, pinout and thermal pad layout against the current manufacturer datasheet before design-in.
Can you help confirm the STC3100IQT parameters?
Yes. Tell us the parameters you are qualifying (supply voltage, current rating, frequency, interface, temperature range or package) and our team will help you confirm them against the current manufacturer datasheet. We do not host third-party datasheets.
Do you quote volume orders for STC3100IQT?
Yes. We quote volume pricing, available quantity and lead time within 2 working hours, and we can consolidate STC3100IQT with other line items into a single shipment.
