TA0224A — Overview
TA0224A by Tai-Saw Technology is a component in the SAW Filter (RF SAW Band-pass Filter For GPS) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
Tai-Saw TA0224A GPS RF SAW band-pass filter centred at 1575.42 MHz with 2 MHz bandwidth, 2.6 dB typical insertion loss and 50 Ohm impedance, in a 3.0 x 3.0 x 1.4 mm surface-mount package.
Key specifications
| Part number | TA0224A |
| Manufacturer | Tai-Saw Technology |
| Device type | SAW Filter (RF SAW Band-pass Filter For GPS) |
| Package | SMD 3.0 x 3.0 mm (SMD3030) |
| Package size | 3.0 x 3.0 x 1.4 mm |
| Stock | 1,861 pcs |
| Date code | 19+ |
| Condition | Original, genuine & unused |
Datasheet parameters
| filter_type | RF SAW band-pass filter, GPS band |
| center_frequency | 1575.42 MHz |
| bandwidth | 2 MHz |
| insertion_loss | 2.6 dB typ / 3.5 dB max (within Fc +/- 1 MHz) |
| amplitude_ripple | 0.1 dB typ / 1.0 dB max (p-p, within Fc +/- 1 MHz) |
| VSWR | 1.5 typ / 2.5 max |
| attenuation | 35 dB min @ 880-915 MHz; 47 dB typ @ 1525.42 MHz; 62.5 dB typ @ 1615.42 MHz |
| source_load_impedance | 50 Ohm |
| max_input_level | +10 dBm |
| operating_temperature | -40 to +85 C |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Stock, date code and availability
| Item | Detail |
|---|---|
| Available quantity | 1,861 pcs |
| Date code | 19+ |
| Warehouse | Shenzhen, China |
| Condition | Original, genuine & unused |
| Packaging | Tape & reel / tube / tray as supplied by the manufacturer |
Stock levels move quickly. Confirm current availability, date code and lead time with our team before ordering.
Need a quote for TA0224A? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Related RF components
| NBB-500-T1 | SBB-1089Z | RF2373TR7 |
| QPA9426TR13 | SGA3463Z | RFPA5208TR13 |
| SBF-4089Z | WJA1500 | SGA-5263Z |
Browse the full Filters / Crystal Oscillators collection, or request a quote for TA0224A.
Frequently asked questions
Is TA0224A original and genuine?
Yes. We supply TA0224A as original, unused stock sourced through long-verified, traceable channels, and we state the date code on every quotation. Traceability documents and inspection reports can be provided on request.
How much TA0224A stock do you have?
1,861 pcs are currently listed (date code 19+). Stock moves daily - send us your required quantity and we will confirm live availability and lead time.
What package does TA0224A use?
TA0224A is supplied in a SMD 3x3mm package (3.0 x 3.0 x 1.4 mm). Always confirm the package, pinout and thermal pad layout against the current manufacturer datasheet before design-in.
Can you help confirm the TA0224A parameters?
We do not host third-party datasheets. Send us the part number and the parameters you are qualifying (frequency, gain, power, package or temperature range) and our team will help you confirm them against the manufacturer data.
Do you quote volume orders for TA0224A?
Yes. We quote volume pricing, date code and lead time within 2 working hours, and we can consolidate TA0224A with other line items into a single shipment.
