Plenty of products need to know the time even when they are not connected: data loggers, meters, access control, appliances and anything that timestamps an event. The real-time clock IC is a small part that causes a disproportionate number of support questions, usually because of the backup supply rather than the chip. Here is how to choose and what to check.
1. The three decisions
- Accuracy — do you need minutes per year, or is drift of seconds per day acceptable? This decides whether you need integrated temperature compensation.
- Interface — I²C for two-pin simplicity, SPI where you prefer it; the RTC itself is slow either way.
- Integration — an RTC with an internal crystal and TCXO removes layout risk; a discrete-crystal part is cheaper but demands careful board design.
2. RTC parts we stock
| Part | Notes | Link |
|---|---|---|
| DS3231SN | High-accuracy RTC with integrated TCXO | DS3231SN |
| DS1307ZN+ | Classic I2C RTC, external 32.768 kHz crystal | DS1307ZN+ |
| PCF8563T/F4 | Low-power I2C RTC with alarm and timer | PCF8563T/F4 |
| Si52147-A01AGMR | Clock generator for multi-output clock distribution | Si52147-A01AGMR |
3. The backup supply is the real design task
An RTC that loses time on power-down is almost never a faulty IC. Work through this:
- Confirm there is a backup source — coin cell, supercapacitor — on the correct pin.
- Check the isolation: a diode or trickle-charge circuit must let the backup supply the RTC when main power drops, without draining back into the main rail.
- Verify the backup voltage is within the RTC's specified range. Too low and the oscillator stops; too high and you damage the part.
- Measure the backup current. A leaky path can flatten a coin cell in weeks instead of years.
4. Layout notes for crystal-based RTCs
If you use an RTC with an external 32.768 kHz crystal, the layout is part of the design: keep the crystal and its load capacitors as close to the IC as possible, keep other traces away from that node, and guard it from thermal gradients. A crystal that is electrically correct but badly placed will still drift.
Selection checklist
- Decide the accuracy target first; it chooses the family.
- Pick the interface that fits your spare pins.
- Design and test the backup path explicitly—do not assume it works.
- For discrete-crystal parts, treat the crystal layout as a first-class design task.
- Confirm the alarm and interrupt features actually match what your firmware expects.
Browse the interface and timing device range and crystals and oscillators. Send your accuracy and interface requirement for a quote.
Frequently asked questions
Which is more accurate, the DS3231 or the DS1307?
The DS3231 uses an integrated temperature-compensated crystal oscillator (TCXO) and holds accuracy to a few minutes per year. The DS1307 relies on an external crystal and is far more sensitive to temperature, drifting noticeably over a wide range. If long-term accuracy matters, the DS3231 is the better choice.
Why does my RTC lose time when the product is powered off?
Almost always a backup-supply problem. The RTC needs a coin cell or supercapacitor on its backup pin, and the trickle-charge or diode arrangement must actually connect it when main power drops. Check the backup path and the cell voltage before blaming the part.
Do I need an external crystal with an RTC IC?
Some RTCs integrate the crystal and compensation; others require a 32.768 kHz crystal and load capacitors. Integrated parts remove the layout sensitivity but cost more. Discrete-crystal parts need careful layout: keep the crystal close, guard it from noise and match the load capacitance.
What is the difference between I2C and SPI RTCs?
Functionally they are the same timekeeping device with a different host interface. Choose based on what your microcontroller has spare. I2C uses two pins and shares the bus; SPI is faster but uses more pins. For an RTC, speed almost never matters, so I2C is usually the practical choice.
