FH101-G
-
When You'll Get It:Aug 25 - Aug 29
-
Shipping & Support: In-stock items ship in 24 hours; custom orders ship per contract. Free shipping on orders over $10,000. For bulk buys, get a personal support rep and quick reimbursement if anything's defective.
**Description**
- 0.05 – 4 GHz GaAs MESFET
- High dynamic range FET packaged in a low-cost surface-mount package
- The combination of low noise figure and high output IP3 at the same bias point makes it ideal for receiver and transmitter applications
- Utilizes high reliability GaAs MESFET technology
- Available in environmentally friendly lead-free / green / RoHS-compliant SOT-89 package
- **Product Status:** Discontinued / Obsolete – Please use Qorvo TQP3M9028 for new designs
**Features**
- Frequency range: 50 to 4000 MHz
- Gain: 18 dB to 19 dB
- Output P1dB: +18 dBm
- Output IP3 (OIP3): +36 dBm
- Low noise figure
- Single or dual supply operation
- MTTF > 100 years at mounting temperatures of +85°C
- Lead-free / green / RoHS compliant
- SOT-89 package
**Key Specifications**
- Frequency Range: 50 MHz to 4000 MHz
- Gain: 18 dB to 19 dB
- Output P1dB: +18 dBm
- Output IP3 (OIP3): +36 dBm
- Noise Figure: 2 dB
- Supply Voltage (Vd): 5 V
- Supply Current (Idq): 150 mA
- Package: SOT-89
- Lead-free / RoHS compliant
- MTTF: >100 years @ +85°C
**Applications**
- Mobile Infrastructure
- CATV / DBS
- W-LAN / ISM
- Defense / Homeland Security
- GPRS, GSM, CDMA, and W-CDMA wireless technologies
- Fixed wireless within 50 to 4000 MHz frequency range
---
> **Note:** All parameters are subject to the official Qorvo FH101-G datasheet. Specifications are typical values and may vary with operating conditions. This product is discontinued – not recommended for new designs. For new designs, please refer to Qorvo TQP3M9028.
