FLU10XMT — Overview
FLU10XMT by Sumitomo Electric is a component in the RF Power Transistor (L-band Medium/high Power GAAS FET, Discrete) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
Sumitomo FLU10XMT L-band medium/high power GaAs FET delivering 29.5 dBm typical P1dB output with 14.5 dB gain and 47% power-added efficiency at 2 GHz, supplied in a hermetic metal/ceramic XM surface-mount package.
Key specifications
| Part number | FLU10XMT |
| Manufacturer | Sumitomo Electric |
| Device type | RF Power Transistor (L-band Medium/high Power GAAS FET, Discrete) |
| Package | XM case - hermetic metal/ceramic surface-mount package (Gate / Source / Drain) |
| Package size | approx. 6.3 x 4.4 mm (XM case body, per outline drawing) |
| Stock | 1,868 pcs |
| Date code | 19+ |
| Condition | Original, genuine & unused |
Datasheet parameters
| technology | GaAs N-channel junction FET (discrete, hermetic metal/ceramic SMT) |
| frequency_range | L-band (PCN/PCS); parameters measured at 2.0 GHz |
| output_power_P1dB | 29.5 dBm typ (28.5 dBm min) |
| gain_G1dB | 14.5 dB typ (13.5 dB min) |
| power_added_efficiency | 47% typ |
| drain_current | 300 mA typ (450 mA max) |
| transconductance | 150 mS |
| pinch_off_voltage | -2.0 V typ |
| drain_source_voltage | 15 V max (operation recommended <= 10 V) |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: FLU10XMT is the tape-and-reel version of the FLU10XM; the 'T' suffix indicates tape and reel. Package_size is approximated from the XM-case outline drawing (0.248 x 0.173 in), matching the sibling FLU35XMT entry. Original datasheet is the Eudyna/Fujitsu FLU10XM publication (Edition 1.2, July 1999); the part is now obsolete.
Stock, date code and availability
| Item | Detail |
|---|---|
| Available quantity | 1,868 pcs |
| Date code | 19+ |
| Warehouse | Shenzhen, China |
| Condition | Original, genuine & unused |
| Packaging | Tape & reel / tube / tray as supplied by the manufacturer |
Stock levels move quickly. Confirm current availability, date code and lead time with our team before ordering.
Need a quote for FLU10XMT? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Related RF components
| NBB-500-T1 | SBB-1089Z | RF2373TR7 |
| QPA9426TR13 | SGA3463Z | RFPA5208TR13 |
| SBF-4089Z | WJA1500 | SGA-5263Z |
Browse the full Interface Chips / RF Chips collection, or request a quote for FLU10XMT.
Frequently asked questions
Is FLU10XMT original and genuine?
Yes. We supply FLU10XMT as original, unused stock sourced through long-verified, traceable channels, and we state the date code on every quotation. Traceability documents and inspection reports can be provided on request.
How much FLU10XMT stock do you have?
1,868 pcs are currently listed (date code 19+). Stock moves daily - send us your required quantity and we will confirm live availability and lead time.
What package does FLU10XMT use?
FLU10XMT is supplied in a XM Case package (approx. 6.3 x 4.4 mm (XM case body, per outline drawing)). Always confirm the package, pinout and thermal pad layout against the current manufacturer datasheet before design-in.
Can you help confirm the FLU10XMT parameters?
We do not host third-party datasheets. Send us the part number and the parameters you are qualifying (frequency, gain, power, package or temperature range) and our team will help you confirm them against the manufacturer data.
Do you quote volume orders for FLU10XMT?
Yes. We quote volume pricing, date code and lead time within 2 working hours, and we can consolidate FLU10XMT with other line items into a single shipment.
