MA4P7447-1141T — Overview
MA4P7447-1141T by M/A-COM is a PIN Diode in a SOD-323 package, supplied by Shenzhen Jingteng Electronics (JTDZ Tech). A silicon PIN diode from M/A-COM (MACOM) SMPP series in a low-cost SOD-323 surface-mount package, intended for use as an RF switch or attenuator across 15–2500 MHz in microwave control circuits.
Key Specifications
| Part Number | MA4P7447-1141T |
|---|---|
| Manufacturer | M/A-COM (MACOM) |
| Device Type | Silicon PIN Diode (single) |
| Breakdown Voltage | 100 V min |
| Total Capacitance | 1.31 pF (1.2 pF @ 20 V) |
| Series Resistance | 0.60 Ω |
| Frequency Range | 15 – 2500 MHz |
| Max Current | 150 mA |
| Power Dissipation | 0.20 W |
| Package | SOD-323 (2L) |
Datasheet Parameters
| Breakdown Voltage | 100 V (min) |
|---|---|
| Total Capacitance | 1.31 pF @ 50 V, 1 MHz |
| Series Resistance | 0.60 Ω @ 10 mA, 100 MHz |
| Max RF Current | 150 mA |
| Operating Temperature | up to 175 °C (TJ) |
| Applications | ISM switches / attenuators |
Applications
- RF switches
- attenuators
- ISM band control circuits
- high-frequency microwave control
Stock & Packaging
Active product, in stock at JTDZ Tech. Original, genuine and unused parts with traceable date code; Certificate of Conformity available on request. Ships within 24 hours from JTDZ Tech stock.
FAQ
- Is the MA4P7447-1141T genuine and traceable?
Yes. JTDZ Tech (Shenzhen Jinteng Electronics) supplies the M/A-COM MA4P7447-1141T as original, genuine parts with traceable date codes and a Certificate of Conformity available on request. - What package does the MA4P7447-1141T use?
It is housed in a SOD-323 package, suitable for automated assembly and high-density RF / microwave designs. - What are the typical applications of the MA4P7447-1141T?
It suits RF switch and attenuator circuits, ISM-band control and general microwave control where low distortion and low loss are needed. - Is the MA4P7447-1141T still in production?
Active product, in stock at JTDZ Tech. - What is the lead time and shipping?
In stock at JTDZ Tech — ships within 24 hours. Each lot carries a traceable date code; small-batch, prototype and repair quantities are supported. - Can I get the full datasheet?
Yes. The complete M/A-COM MA4P7447-1141T datasheet (electrical characteristics, S-parameters, footprint and reel specs) is available on request — contact JTDZ Tech sales for the PDF and reference designs.
