PE42520C-Z — Overview
PE42520C-Z by pSemi is a component in the RF Switch (SPDT absorptive, 9 kHz-13 GHz) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The PE42520C-Z is a broadband absorptive SPDT RF switch built on pSemi's UltraCMOS silicon-on-sapphire process with HaRP technology, covering 9 kHz to 13 GHz in a 16-lead 3 x 3 mm QFN. It delivers 0.80 dB insertion loss and 45 dB isolation at 3 GHz, 66 dBm IIP3, and 36 dBm CW power handling at 8 GHz, with fast 5.5 µs switching and no gate or phase lag. It is aimed at ATE, test-and-measurement and high-performance wireless signal routing.
Key specifications
| Part number | PE42520C-Z |
| Manufacturer | pSemi |
| Device type | UltraCMOS SPDT Absorptive RF Switch |
| Package | QFN-16 |
| Package size | 3 x 3 mm, 16-lead |
| Stock | 5,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Switch configuration | SPDT, absorptive (50 Ω terminated) |
| Frequency range | 9 kHz to 13 GHz |
| Insertion loss @ 3 GHz | 0.80 dB typ |
| Insertion loss @ 10 GHz | 0.90 dB typ |
| Insertion loss @ 13 GHz | 2.0 dB typ |
| Isolation @ 3 GHz | 45 dB typ |
| Isolation @ 10 GHz | 31 dB typ |
| Isolation @ 13 GHz | 18 dB typ |
| Input IP3 | 66 dBm typ |
| RF power, CW (10 MHz-8 GHz) | 36 dBm max |
| Supply voltage VDD | 2.3 to 5.5 V |
| Supply current IDD | 120 µA typ (200 µA max) |
| Control voltage (CTRL high/low) | 1.17 to 3.6 V / -0.3 to 0.6 V |
| Switching / settling time | 5.5 µs / 15 µs typ |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Note: Corrected from the request: the PE42520C-Z is an SPDT (not SP4T) absorptive switch; the pSemi ordering table lists PE42520C-Z as 'PE42520 SPDT RF switch, Green 16-lead 3 x 3 mm QFN, 3000 units/T&R'. P0.1dB compression is specified graphically in the datasheet (Figure 3), so no single numeric P1dB is quoted here. Part is active/production.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 5,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray, tube or bulk as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for PE42520C-Z? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Interface Chips / RF Chips collection for more SPDT RF Switch devices, or request a quote for PE42520C-Z.
Other pSemi parts in stock
| PE43610A-X | PE42441E-Z | PE42551-52 |
| PE3502-51 | PE42540G-Z | PE42462A-X |
Frequently asked questions
Is PE42520C-Z original and genuine?
Yes. We supply PE42520C-Z as original, unused stock sourced through long-verified, traceable channels. Traceability documents, inspection reports and photos of the actual goods can be provided on request before you commit.
How much PE42520C-Z stock do you have?
5,000 pcs of PE42520C-Z are currently listed. Stock moves daily - send us your required quantity and we will confirm live availability, date code and lead time.
What package does PE42520C-Z use?
PE42520C-Z is supplied in a QFN-16 package (3 x 3 mm, 16-lead). Always confirm the package, pinout and land pattern against the current manufacturer datasheet before design-in.
Can you help confirm the PE42520C-Z parameters?
Yes. Tell us the parameters you are qualifying (frequency range, gain, attenuation, voltage, current or temperature range) and our team will help you confirm them against the current manufacturer datasheet. We do not host third-party datasheets.
Do you quote volume orders for PE42520C-Z?
Yes. We quote volume pricing, available quantity and lead time within 2 working hours, and we can consolidate PE42520C-Z with other line items into a single shipment.
All trademarks, brand names and part numbers are the property of their respective owners. JTDZ Tech is an independent distributor and is not an authorised distributor, franchisee or agent of the manufacturers named above.
