TDA22590 — Overview
TDA22590 by Infineon Technologies is a component in the Power Management - Integrated Power Stage (OptiMOS Smart Power Stage) category, supplied by Shenzhen Jinteng Electronics Technology Co., Ltd. (JTDZ Tech) — an independent distributor serving OEMs, ODMs and EMS providers worldwide.
The TDA22590 is an Infineon OptiMOS 6 integrated power stage that embeds a low-quiescent-current synchronous buck gate driver together with control and synchronous MOSFETs in a small 4 x 6 x 0.465 mm Chip-Embedded (CE) package (Infineon PG-UFLGA-34). It delivers up to 90 A continuous output, operates from a 4.25-V to 16-V input at switching frequencies up to 2 MHz, and reports current at 5 uA/A with 8-mV/C analog temperature telemetry. It is aimed at high-current CPU, GPU, FPGA and DDR memory voltage regulators in servers, AI data centers and telecom equipment.
Key specifications
| Part number | TDA22590 |
| Manufacturer | Infineon Technologies |
| Device type | Power Management - Integrated Power Stage (OptiMOS Smart Power Stage) |
| Package | UFLGA-34 |
| Package size | 4.00 x 6.00 x 0.465 mm |
| Stock | 20,000 pcs |
| Condition | Original, genuine & unused |
Datasheet parameters
| Device Type | Integrated Power Stage (OptiMOS 6: driver + Schottky diode + control/sync MOSFETs) |
| Output Current (continuous) | 90 A (0 A to 90 A) |
| Input Voltage (VIN) Range | 4.25 V to 16 V |
| VCC / VDRV Supply | 4.5 V to 5.5 V |
| Output Voltage Range (at VIN = 12 V) | 0.225 V to 5.5 V |
| Switching Frequency | 200 kHz to 2000 kHz (up to 2 MHz) |
| On-chip Current Reporting | 5 uA/A |
| Temperature Telemetry Output | 8 mV/C analog |
| Deep-Sleep Quiescent Current (EN low, typ) | 32 uA |
| PWM Input | 3.3 V tri-state compatible |
| Operating Temperature Range | -40C to +125C |
| Package | 4 x 6 x 0.465 mm CE (Chip Embedded), Infineon PG-UFLGA-34, 34 pins |
Parameters above are transcribed from the manufacturer datasheet for reference only. Confirm the current datasheet revision and your application conditions before design-in.
Stock, packaging and availability
| Item | Detail |
|---|---|
| Available quantity | 20,000 pcs |
| Condition | Original, genuine & unused |
| Packaging | Original factory packaging — tape & reel, tray or tube as supplied by the manufacturer |
| Warehouse | Shenzhen, China |
| Lead time | Confirmed per order — typically ships within 24–48 hours after payment |
Stock levels move quickly. Confirm current availability, quantity and lead time with our team before ordering.
Need a quote for TDA22590? Send your target quantity, destination and required date code to our sales team — we reply with price, stock and lead time within 2 working hours.
Browse the full Power Management Chips collection for more 90A Integrated Power Stage devices, or request a quote for TDA22590.
Frequently asked questions
Is TDA22590 original and genuine?
Yes. We supply TDA22590 as original, unused stock sourced through long-verified, traceable channels. Traceability documents, inspection reports and photos of the actual goods can be provided on request before you commit.
How much TDA22590 stock do you have?
20,000 pcs of TDA22590 are currently listed. Stock moves daily - send us your required quantity and we will confirm live availability, date code and lead time.
What package does TDA22590 use?
TDA22590 is supplied in a UFLGA-34 package (4.00 x 6.00 x 0.465 mm). Always confirm the package, pinout and thermal pad layout against the current manufacturer datasheet before design-in.
Can you help confirm the TDA22590 parameters?
Yes. Tell us the parameters you are qualifying (supply voltage, current rating, frequency, interface, temperature range or package) and our team will help you confirm them against the current manufacturer datasheet. We do not host third-party datasheets.
Do you quote volume orders for TDA22590?
Yes. We quote volume pricing, available quantity and lead time within 2 working hours, and we can consolidate TDA22590 with other line items into a single shipment.
All trademarks, brand names and part numbers are the property of their respective owners. JTDZ Tech is an independent distributor and is not an authorised distributor, franchisee or agent of the manufacturers named above.
