PIN-TO-PIN ALTERNATIVE
NSi8220N0-DSPR is a Chinese-manufactured pin-to-pin drop-in replacement for ADuM1200 / ISO7720 / Si8620 (Analog Devices / Texas Instruments / Skyworks).
Analog Devices / TI / Skyworks cross-reference in the same footprint, with lower propagation delay and roughly half the price.
NSi8220N0-DSPR — Alternative to ADuM1200 / ISO7720 / Si8620
NSi8220N0-DSPR from Novosense {BRAND} is supplied by JTDZ Tech (Shenzhen Jingteng Electronics) as a cost-effective, short-lead-time alternative to the imported ADuM1200 / ISO7720 / Si8620 (Analog Devices / Texas Instruments / Skyworks). Chinese-sourced semiconductors have moved well beyond "cheap substitute" status: the parts below are production-validated in industrial, automotive and consumer designs, and they remove both the allocation risk and the long lead times that come with imported.
Cross-Reference: ADuM1200 / ISO7720 / Si8620 vs NSi8220N0-DSPR
| imported | This part (Chinese alternative) | |
|---|---|---|
| Part number | ADuM1200 / ISO7720 / Si8620 | NSi8220N0-DSPR |
| Manufacturer | Analog Devices / Texas Instruments / Skyworks | Novosense {BRAND} |
| Package | SOP-8 / SOW8 / SOW16 | SOP-8 / SOW8 / SOW16 |
| Compatibility | — | Pin-to-Pin drop-in replacement |
| Supply & lead time | Frequently allocated, long lead times | Domestic stock, short lead time |
| Description | Interface Chips/RF Chips, DC to 150 Mbps, 2.5 V - 5.5 V, SOP-8 / SOW8 / SOW16 package. |
Key Specifications
| Channels | 2 forward / 0 reverse (same direction) |
| Data rate | DC to 150 Mbps |
| Isolation | 3.75 kVrms / 5 kVrms / 5.7 kVrms |
| CMTI | Up to 200 kV/us |
| Supply | 2.5 V - 5.5 V |
| ESD | HBM +/-8 kV |
| Power | 1.5 mA per channel at 1 Mbps |
| Propagation delay | <15 ns |
| Temperature | -55 C to +125 C |
What to check before substituting NSi8220N0-DSPR for ADuM1200
- Package and pinout are compatible with ADuM1200-class parts, so the footprint is unchanged and propagation delay is lower.
- Channel direction must match your design: NSi8220 is 2 forward / 0 reverse, which corresponds to ADuM1200. If your design uses ADuM1201 (1 forward / 1 reverse), choose the NSi8221 or NSi8222 instead.
- Wide 2.5 V to 5.5 V supply on both sides simplifies level shifting between 3.3 V and 5 V logic.
- Isolation barrier lifetime is specified above 60 years.
Typical Applications
- Industrial automation and motor control
- Isolated SPI, RS-232 and RS-485 interfaces
- General-purpose multichannel isolation
- New-energy and power conversion designs
Why buy NSi8220N0-DSPR from JTDZ Tech
- and new parts from Novosense {BRAND}, with traceable date codes
- MOQ 1 pc, tier pricing for volume and BOM kitting
- Cross-reference and substitution support: send us your BOM and we will confirm pin-to-pin compatibility before you commit
- X-ray, visual inspection and third-party lab testing supported on request
- Quote within 2 business hours; export shipping to India, Vietnam, the Middle East and worldwide
Need NSi8220N0-DSPR, or still prefer the ADuM1200? Send us your part list and target quantity — we will come back with pricing, stock and a compatibility confirmation within 2 business hours. Prices vary with quantity and market conditions, so the listed price is for reference only.
Genuine original parts guaranteed — traceable lot & date code, X-ray / visual inspection and third-party test supported before shipment.
