PIN-TO-PIN ALTERNATIVE
TPT7720-SO1R is a Chinese-manufactured pin-to-pin drop-in replacement for ADuM1200 (Analog Devices).
3PEAK's pin-compatible isolator family, with AEC-Q100 qualified variants for automotive designs.
TPT7720-SO1R — Alternative to ADuM1200
TPT7720-SO1R from 3PEAK {BRAND} is supplied by JTDZ Tech (Shenzhen Jingteng Electronics) as a cost-effective, short-lead-time alternative to the imported ADuM1200 (Analog Devices). Chinese-sourced semiconductors have moved well beyond "cheap substitute" status: the parts below are production-validated in industrial, automotive and consumer designs, and they remove both the allocation risk and the long lead times that come with imported.
Cross-Reference: ADuM1200 vs TPT7720-SO1R
| imported | This part (Chinese alternative) | |
|---|---|---|
| Part number | ADuM1200 | TPT7720-SO1R |
| Manufacturer | Analog Devices | 3PEAK {BRAND} |
| Package | SOP-8 | SOP-8 |
| Pin Count | 8 | |
| Compatibility | — | Pin-to-Pin drop-in replacement |
| Supply & lead time | Frequently allocated, long lead times | Domestic stock, short lead time |
| Description | Interface Chips/RF Chips, 150 Mbps, 2.25 V - 5.5 V on both sides, SOP-8 package. |
Key Specifications
| Channels | 2 forward / 0 reverse (TPT7721 / TPT7722 are 1 forward / 1 reverse) |
| Data rate | 150 Mbps |
| Isolation | 3750 Vrms (SOP-8) / 5000 Vrms (WSOP8, WSOP16) |
| CMTI | 150 kV/us minimum |
| Supply | 2.25 V - 5.5 V on both sides |
| Propagation delay | 12 ns typical |
| Temperature | -40 C to +125 C |
| Certification | UL 1577, VDE, CSA, TUV, CQC, CB |
What to check before substituting TPT7720-SO1R for ADuM1200
- Same SOP-8 footprint as ADuM1200-class isolators, so no layout change.
- Capacitive silicon-dioxide barrier technology with fail-safe default output.
- Channel direction matters: TPT7720 is 2 forward / 0 reverse (ADuM1200 equivalent); choose TPT7721 or TPT7722 for 1 forward / 1 reverse (ADuM1201 equivalent).
- The -S suffix variant is AEC-Q100 qualified for automotive use.
Typical Applications
- Industrial automation and motor control
- Isolated data acquisition
- Power conversion and new-energy systems
- Automotive-grade isolation (with -S variant)
Why buy TPT7720-SO1R from JTDZ Tech
- and new parts from 3PEAK {BRAND}, with traceable date codes
- MOQ 1 pc, tier pricing for volume and BOM kitting
- Cross-reference and substitution support: send us your BOM and we will confirm pin-to-pin compatibility before you commit
- X-ray, visual inspection and third-party lab testing supported on request
- Quote within 2 business hours; export shipping to India, Vietnam, the Middle East and worldwide
Need TPT7720-SO1R, or still prefer the ADuM1200? Send us your part list and target quantity — we will come back with pricing, stock and a compatibility confirmation within 2 business hours. Prices vary with quantity and market conditions, so the listed price is for reference only.
Genuine original parts guaranteed — traceable lot & date code, X-ray / visual inspection and third-party test supported before shipment.
