PIN-TO-PIN ALTERNATIVE
X503227MSB4SI is a Chinese-manufactured pin-to-pin drop-in replacement for EPSON FA-20H / KDS 27 MHz (EPSON / KDS / TXC).
27 MHz in the standard 5032 footprint, from a domestic supplier with stock availability.
X503227MSB4SI — Alternative to EPSON FA-20H / KDS 27 MHz
X503227MSB4SI from YXC 扬兴 is supplied by JTDZ Tech (Shenzhen Jingteng Electronics) as a cost-effective, short-lead-time alternative to the imported EPSON FA-20H / KDS 27 MHz (EPSON / KDS / TXC). Chinese-sourced semiconductors have moved well beyond "cheap substitute" status: the parts below are production-validated in industrial, automotive and consumer designs, and they remove both the allocation risk and the long lead times that come with imported.
Cross-Reference: EPSON FA-20H / KDS 27 MHz vs X503227MSB4SI
| imported | This part (Chinese alternative) | |
|---|---|---|
| Part number | EPSON FA-20H / KDS 27 MHz | X503227MSB4SI |
| Manufacturer | EPSON / KDS / TXC | YXC 扬兴 |
| Package | 5032 (5.0 x 3.2 mm) | 5032 (5.0 x 3.2 mm) |
| Compatibility | — | Pin-to-Pin drop-in replacement |
| Supply & lead time | Frequently allocated, long lead times | Domestic stock, short lead time |
| Description | Filters/Crystal Oscillators, 27 MHz, 5032 package. |
Key Specifications
| Frequency | 27 MHz |
| Package | 5032, 5.0 x 3.2 mm - industry-standard footprint |
| Frequency tolerance | +/-10 ppm |
| Operating temperature | -40 C to +85 C |
| Aging | +/-3 ppm per year |
| Series | YSX531SL |
What to check before substituting X503227MSB4SI for EPSON FA-20H
- 5032 is a standard footprint, so a 27 MHz YXC part substitutes directly for EPSON FA-20H or KDS equivalents at matched load capacitance.
- Confirm the required load capacitance and tolerance grade before ordering, as the suffix determines both.
- Wide product range means 27 MHz is a stock frequency, not a custom order.
Typical Applications
- Video and imaging equipment
- Wireless communication modules
- Industrial control and instrumentation
- Consumer electronics
Why buy X503227MSB4SI from JTDZ Tech
- and new parts from YXC 扬兴, with traceable date codes
- MOQ 1 pc, tier pricing for volume and BOM kitting
- Cross-reference and substitution support: send us your BOM and we will confirm pin-to-pin compatibility before you commit
- X-ray, visual inspection and third-party lab testing supported on request
- Quote within 2 business hours; export shipping to India, Vietnam, the Middle East and worldwide
Need X503227MSB4SI, or still prefer the EPSON FA-20H? Send us your part list and target quantity — we will come back with pricing, stock and a compatibility confirmation within 2 business hours. Prices vary with quantity and market conditions, so the listed price is for reference only.
Genuine original parts guaranteed — traceable lot & date code, X-ray / visual inspection and third-party test supported before shipment.
